Onkyo HT-R380 Service Manual

D933 C-DIODE KDS4148U 1 223283R2
D933 or C-DIODE 1SS352 ( 1) 223234R2
D933 or C-DIODE MA2J111 ( 1) 223279R2
D934 ZENER D UDZS5.6B 1 224550560R2 <MPB, MPP, MMO, MMQ>
D934 ZENER D UDZS5.1B 1 224550510R2 <MDC>
D935 C-DIODE KDS4148U 1 223283R2
D935 or C-DIODE 1SS352 ( 1) 223234R2
D935 or C-DIODE MA2J111 ( 1) 223279R2
Q2001 IC NJW1326FH2 1 22242583R3
Q2002 IC NJM2505AF 1 22242490R2
Q2002 or IC BH7673G ( 1) 22242661R2
Q7002 FL TUBE 16-BT-162GNK 1 212273
Q7002A HOLDER (FL) 1 27191222C
Q7003 IC M66005-0001AHP 1 22242208R3
Q7004 TR KTC3875-GR 1 2216175R2
Q7033 TR KTC3875-GR 1 2216175R2
Q9022 IC 78M05(NJM78M05FA) 1 222780055JRC
Q9022 or IC 78M05AHF(MPC78M05AHF) ( 1) 222780055NEC
Q9022A SCREW 3P+10FN(3BC) 1 82143010GR
Q9022B HEAT SINK RAD-157 1 27160491
Q9031 IC MPC2905BHF 1 22278005DBNE
Q9031A SCREW 3P+10FN(3BC) 1 82143010GR
Q9031B HEAT SINK RAD-140 1 27160471
[TRANS COIL]
L7031 CHOKE COIL LBC2518T2R2M 1 231364M022R2
L7032 CHOKE COIL LBC2518T2R2M 1 231364M022R2
L7201 CHOKE COIL LBC2518T2R2M 1 231364M022R2
L7202
CHOKE COIL LBC2518T2R2M 1 231364M022R2
L7203 CHOKE COIL LBC2518T2R2M 1 231364M022R2
T902 P TRANS ( ! ) NPT-1520JQ 1 2301812A <MDC>
T902 P TRANS ( ! ) NPT-1520GQ 1 2301813A <MPB, MPP, MMO, MMQ>
[CAPACITOR]
C2001 VR C CE04W50V-10M(VR) 1 394681007T
C2002 C-CERA C CK725F1E-104Z1 1 332161040R1
C2003 VR C CE04W6.3V-470M(VR) 1 394624717T
C2004 C-CERA C CC725CH1H-470J1 1 342104704R1
C2005 VR C CE04W6.3V-470M(VR) 1 394624717T
C2006 C-CERA C CC725CH1H-470J1 1 342104704R1
C2011 C-CERA C CK725F1A-105Z1 1 332181050R1
C2012 C-CERA C CK725F1A-105Z1 1 332181050R1
C2013 C-CERA C CK725F1A-105Z1 1 332181050R1
C2014 C-CERA C CK725F1A-105Z1 1 332181050R1

Onkyo HT-R380 Specifications

General

Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Weight	17.6 lbs
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Surround System Class	5.1 channel
Digital Sound Processor (DSP)	Yes
HDMI Switching	Yes
Bluetooth	No
HDMI Version	1.4a
Power Output	100W per channel (6 ohms, 1 kHz, 1% THD, 1 channel driven)
Dolby Technologies	Dolby Digital, Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio
DSP Presets	Game, Movie, Music
Input Video Formats	HDMI
Audio D/A Converter	24bit / 192kHz
Inputs	HDMI, Composite, Optical, Coaxial
Outputs	HDMI, Composite
