Onkyo HT-R391 User Manual

Turning On & Basic Operations
En-24
This section explains how to play music files from a USB
device (e.g., USB flash drives and MP3 players).
See also:
• “USB Features” (➔ page 63).
Note
• While the message “Connecting...” appears on the AV receiver’s
display, do not disconnect the USB cable supplied with your
iPod/iPhone or the USB device from the USB port.
Playing a USB Device
The on-screen menus appear only on a TV that is
connected to the HDMI OUT.
1
Press USB to select the “USB” input.
2
Plug your USB device into the AV receiver’s USB
port.
While reading the contents of your USB device, the
message “Connecting...” appears on the AV
receiver’s display.
3
Press ENTER.
A list of the device’s contents appears. To open a
folder, use q/w to select it, and then press ENTER.
4
Use q/w to select a music file, and press ENTER or
1 to start playback.

Onkyo HT-R391 Specifications

General

Type	AV Receiver
Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
4K Passthrough	Yes
3D Support	Yes
Audio Return Channel (ARC)	Yes
Frequency Response	20 Hz - 50 kHz
Bluetooth	No
Video Upscaling	No
Power Output	100W per channel (6 ohms, 1 kHz, 1% THD)
Dolby Formats	Dolby TrueHD, Dolby Digital Plus
DTS Formats	DTS-HD Master Audio
Dimensions	435 x 150 x 318 mm
Inputs	HDMI, Optical, Coaxial, Analog Audio
Outputs	HDMI
Weight	16.5 lbs (7.5 kg)
