Onkyo HT-R520 Service Manual

29/40 PAGE
PCB
Q212 IC LA7956 1 22241759
PCB
Q213 IC LA7956 1 22241759
PCB
Q281 IC 74HCU04F 1 222740046R2
PCB
Q921 TR KTC3199-GR 1 2215864
PCB
Q921 or TR 2SC2458-GR ( 1) 2212115
PCB
Q921 or TR 2SC1740S-R ( 1) 2213284
PCB
Q921 or TR 2SC1740S-S ( 1) 2213285
PCB
Q6010 TR 2SC1740S-R 1 2213284
PCB
Q6010 or TR 2SC1740S-S ( 1) 2213285
PCB
Q6011 TR 2SC1740S-R 1 2213284
PCB
Q6011 or TR 2SC1740S-S ( 1) 2213285
PCB
Q6012 TR 2SC1740S-R 1 2213284
PCB
Q6012 or TR 2SC1740S-S ( 1) 2213285
PCB
Q6013 TR 2SC1740S-R 1 2213284
PCB
Q6013 or TR 2SC1740S-S ( 1) 2213285
PCB
Q6014 TR 2SC1740S-R 1 2213284
PCB
Q6014 or TR 2SC1740S-S ( 1) 2213285
PCB
Q6015 TR 2SC1740S-R 1 2213284
PCB
Q6015 or TR 2SC1740S-S ( 1) 2213285
PCB
Q6020 TR 2SC1740S-R 1 2213284
PCB
Q6020 or TR 2SC1740S-S ( 1) 2213285
PCB
Q6021 TR 2SC1740S-R 1 2213284
PCB
Q6021 or TR 2SC1740S-S ( 1) 2213285
PCB
Q6022 TR 2SC1740S-R 1 2213284
PCB
Q6022 or TR 2SC1740S-S ( 1) 2213285
PCB
Q6023 TR 2SC1740S-R 1 2213284
PCB
Q6023 or TR 2SC1740S-S ( 1) 2213285
PCB
Q6024 TR 2SC1740S-R 1 2213284
PCB
Q6024 or TR 2SC1740S-S ( 1) 2213285
PCB
Q6025 TR 2SC1740S-R 1 2213284
PCB
Q6025 or TR 2SC1740S-S ( 1) 2213285
PCB
Q6030 TR KTD2061-Y 1 2203434
PCB
Q6030 or TR 2SC5171 ( 1) 2203010
PCB
Q6031 TR KTD2061-Y 1 2203434
PCB
Q6031 or TR 2SC5171 ( 1) 2203010
PCB
Q6032 TR KTD2061-Y 1 2203434
PCB
Q6032 or TR 2SC5171 ( 1) 2203010
PCB
Q6033 TR KTD2061-Y 1 2203434
<520>
PCB
Q6033 or TR 2SC5171 ( 1) 2203010
<520>
PCB
Q6033 TR 2SC5511-E 1 2203845
<502>,<502E>,<8250>
PCB
Q6033 or TR KTD2061-Y ( 1) 2203434
<502>,<502E>,<8250>
PCB
Q6033 or TR 2SC5171 ( 1) 2203010
<502>,<502E>,<8250>
PCB
Q6034 TR KTD2061-Y 1 2203434
<520>
PCB
Q6034 or TR 2SC5171 ( 1) 2203010
<520>
PCB
Q6034 TR 2SC5511-E 1 2203845
<502>,<502E>,<8250>
PCB
Q6034 or TR KTD2061-Y ( 1) 2203434
<502>,<502E>,<8250>
PCB
Q6034 or TR 2SC5171 ( 1) 2203010
<502>,<502E>,<8250>
PCB
Q6035 TR KTD2061-Y 1 2203434
<520>
PCB
Q6035 or TR 2SC5171 ( 1) 2203010
<520>
PCB
Q6035 TR 2SC5511-E 1 2203845
<502>,<502E>,<8250>
PCB
Q6035 or TR KTD2061-Y ( 1) 2203434
<502>,<502E>,<8250>
PCB
Q6035 or TR 2SC5171 ( 1) 2203010
<502>,<502E>,<8250>
PCB
Q6040 TR KTB1369-Y 1 2203424
PCB
Q6040 or TR 2SA1930 ( 1) 2203000
PCB
Q6041 TR KTB1369-Y 1 2203424
PCB
Q6041 or TR 2SA1930 ( 1) 2203000
PCB
Q6042 TR KTB1369-Y 1 2203424
PCB
Q6042 or TR 2SA1930 ( 1) 2203000
PCB
Q6043 TR KTB1369-Y 1 2203424
<520>
PCB
Q6043 or TR 2SA1930 ( 1) 2203000
<520>
PCB
Q6043 TR 2SA2005-E 1 2203835
<502>,<502E>,<8250>
PCB
Q6043 or TR KTB1369-Y ( 1) 2203424
<502>,<502E>,<8250>
PCB
Q6043 or TR 2SA1930 ( 1) 2203000
<502>,<502E>,<8250>
PCB
Q6044 TR KTB1369-Y 1 2203424
<520>
PCB
Q6044 or TR 2SA1930 ( 1) 2203000
<520>
PCB
Q6044 TR 2SA2005-E 1 2203835
<502>,<502E>,<8250>
PCB
Q6044 or TR KTB1369-Y ( 1) 2203424
<502>,<502E>,<8250>
PCB
Q6044 or TR 2SA1930 ( 1) 2203000
<502>,<502E>,<8250>
PCB
Q6045 TR KTB1369-Y 1 2203424
<520>
PCB
Q6045 or TR 2SA1930 ( 1) 2203000
<520>
PCB
Q6045 TR 2SA2005-E 1 2203835
<502>,<502E>,<8250>
PCB
Q6045 or TR KTB1369-Y ( 1) 2203424
<502>,<502E>,<8250>
PCB
Q6045 or TR 2SA1930 ( 1) 2203000
<502>,<502E>,<8250>
