Onkyo HT-R520 Service Manual

31/40 PAGE
PCB
Q6073 or TR KTC3200-GR ( 1) 2215895
<502E>,<8250>
PCB
Q6073 or TR 2SC1775A-E ( 1) 2210755
<502E>,<8250>
PCB
Q6073 or TR 2SC1775A-F ( 1) 2210756
<502E>,<8250>
PCB
Q6073 or TR 2SC1845-F ( 1) 2211732
<502E>,<8250>
PCB
Q6073 or TR 2SC1845-E ( 1) 2211733
<502E>,<8250>
PCB
Q6073 TR 2SC2631-R 1 2214984
<520>
PCB
Q6073 or TR 2SC2631-S ( 1) 2214985
<520>
PCB
Q6074 TR KTC3200-BL 1 2215896
<502 DD,DC>
PCB
Q6074 or TR KTC3200-GR ( 1) 2215895
<502 DD,DC>
PCB
Q6074 or TR 2SC1775A-E ( 1) 2210755
<502 DD,DC>
PCB
Q6074 or TR 2SC1775A-F ( 1) 2210756
<502 DD,DC>
PCB
Q6074 or TR 2SC1845-F ( 1) 2211732
<502 DD,DC>
PCB
Q6074 or TR 2SC1845-E ( 1) 2211733
<502 DD,DC>
PCB
Q6074 TR KTC3200-BL 1 2215896
<502 PA,PT,GR,GK,GQ,WT>
PCB
Q6074 or TR KTC3200-GR ( 1) 2215895
<502 PA,PT,GR,GK,GQ,WT>
PCB
Q6074 or TR 2SC1775A-E ( 1) 2210755
<502 PA,PT,GR,GK,GQ,WT>
PCB
Q6074 or TR 2SC1775A-F ( 1) 2210756
<502 PA,PT,GR,GK,GQ,WT>
PCB
Q6074 or TR 2SC1845-F ( 1) 2211732
<502 PA,PT,GR,GK,GQ,WT>
PCB
Q6074 or TR 2SC1845-E ( 1) 2211733
<502 PA,PT,GR,GK,GQ,WT>
PCB
Q6074 TR KTC3200-BL 1 2215896
<502E>,<8250>
PCB
Q6074 or TR KTC3200-GR ( 1) 2215895
<502E>,<8250>
PCB
Q6074 or TR 2SC1775A-E ( 1) 2210755
<502E>,<8250>
PCB
Q6074 or TR 2SC1775A-F ( 1) 2210756
<502E>,<8250>
PCB
Q6074 or TR 2SC1845-F ( 1) 2211732
<502E>,<8250>
PCB
Q6074 or TR 2SC1845-E ( 1) 2211733
<502E>,<8250>
PCB
Q6074 TR 2SC2631-R 1 2214984
<520>
PCB
Q6074 or TR 2SC2631-S ( 1) 2214985
<520>
PCB
Q6075 TR KTC3200-BL 1 2215896
<502 DD,DC>
PCB
Q6075 or TR KTC3200-GR ( 1) 2215895
<502 DD,DC>
PCB
Q6075 or TR 2SC1775A-E ( 1) 2210755
<502 DD,DC>
PCB
Q6075 or TR 2SC1775A-F ( 1) 2210756
<502 DD,DC>
PCB
Q6075 or TR 2SC1845-F ( 1) 2211732
<502 DD,DC>
PCB
Q6075 or TR 2SC1845-E ( 1) 2211733
<502 DD,DC>
PCB
Q6075 TR KTC3200-BL 1 2215896
<502 PA,PT,GR,GK,GQ,WT>
PCB
Q6075 or TR KTC3200-GR ( 1) 2215895
<502 PA,PT,GR,GK,GQ,WT>
PCB
Q6075 or TR 2SC1775A-E ( 1) 2210755
<502 PA,PT,GR,GK,GQ,WT>
PCB
Q6075 or TR 2SC1775A-F ( 1) 2210756
<502 PA,PT,GR,GK,GQ,WT>
PCB
Q6075 or TR 2SC1845-F ( 1) 2211732
<502 PA,PT,GR,GK,GQ,WT>
PCB
Q6075 or TR 2SC1845-E ( 1) 2211733
<502 PA,PT,GR,GK,GQ,WT>
PCB
Q6075 TR KTC3200-BL 1 2215896
<502E>,<8250>
PCB
Q6075 or TR KTC3200-GR ( 1) 2215895
<502E>,<8250>
PCB
Q6075 or TR 2SC1775A-E ( 1) 2210755
<502E>,<8250>
PCB
Q6075 or TR 2SC1775A-F ( 1) 2210756
<502E>,<8250>
PCB
Q6075 or TR 2SC1845-F ( 1) 2211732
<502E>,<8250>
PCB
Q6075 or TR 2SC1845-E ( 1) 2211733
<502E>,<8250>
PCB
Q6075 TR 2SC2631-R 1 2214984
<520>
PCB
Q6075 or TR 2SC2631-S ( 1) 2214985
<520>
PCB
Q6303 TR KTA1267-GR 1 2215995
PCB
Q6303 or TR 2SA933S-R ( 1) 2213354
PCB
Q6303 or TR 2SA933S-S ( 1) 2213355
PCB
Q6313 TR KTA1267-GR 1 2215995
PCB
Q6313 or TR 2SA933S-R ( 1) 2213354
PCB
Q6313 or TR 2SA933S-S ( 1) 2213355
PCB
Q6601 TR KTC3199-GR 1 2215864
PCB
Q6601 or TR 2SC2458-GR ( 1) 2212115
PCB
Q6601 or TR 2SC1740S-R ( 1) 2213284
PCB
Q6601 or TR 2SC1740S-S ( 1) 2213285
PCB
Q6602 TR KTC3199-GR 1 2215864
PCB
Q6602 or TR 2SC2458-GR ( 1) 2212115
PCB
Q6602 or TR 2SC1740S-R ( 1) 2213284
PCB
Q6602 or TR 2SC1740S-S ( 1) 2213285
PCB
Q6603 TR KTC3199-GR 1 2215864
PCB
Q6603 or TR 2SC2458-GR ( 1) 2212115
PCB
Q6603 or TR 2SC1740S-R ( 1) 2213284
PCB
Q6603 or TR 2SC1740S-S ( 1) 2213285
PCB
Q6701 TR KTC3200-BL 1 2215896
PCB
Q6701 or TR KTC3200-GR ( 1) 2215895
PCB
Q6701 or TR 2SC1775A-E ( 1) 2210755
PCB
Q6701 or TR 2SC1775A-F ( 1) 2210756
PCB
Q6701 or TR 2SC1845-F ( 1) 2211732
PCB
Q6701 or TR 2SC1845-E ( 1) 2211733
PCB
Q6702 TR KTC3200-BL 1 2215896
PCB
Q6702 or TR KTC3200-GR ( 1) 2215895
