Onkyo HT-R520

39/40 PAGE
PCB
P6005 PLUG NPLG-5P0960 1 25056010
PCB
P6011 PLUG NPLG-10P0965 1 25056015
PCB
P6072A TRM NTM-1P232(M1700) 1 25060301
PCB
P6073A TRM NTM-1P232(M1700) 1 25060301
PCB
P6080 PLUG NPLG-2P29 1 25055038
PCB
P6081 PLUG NPLG-2P29 1 25055038
PCB
P6082 PLUG NPLG-2P29 1 25055038
PCB
P6083 PLUG NPLG-2P29 1 25055038
PCB
P6084 PLUG NPLG-2P29 1 25055038
PCB
P6085 PLUG NPLG-2P29 1 25055038
PCB
P6301 PLUG NPLG-3P32 1 25055042
PCB
P6380 SHLD CASE (THERMISTOR) 1 27225154A
PCB
P6903 BUS BAR BBL15 1 27141869
PCB
P6906 RETAINER KANAGU 1 27141059
PCB
P6907 TRM(SCREW) NEGITANSI M3 1 25065425
PCB
P6910 TRM(SCREW) NEGITANSI M3 1 25065425
<502 GK>
PCB
P6931 PLUG NPLG-16P761 1 25055805
PCB
P6981 WS CLAMP CB-71694(L=30) 1 260260
PCB
S902 SLIDE SW NSS-22157P 1 25065437
<502 WT>
PCB
S906 PUSH SW NPS-121-L665P 1 25035702
<502 DD,DC>
PCB
S906 PUSH SW NPS-121-L665P 1 25035702
<502 PA,PT,GR,GK,GQ,WT>
PCB
S906 PUSH SW NPS-121-L665P 1 25035702
<502E>,<8250>
PCB
J010 CRIMP AS CRIMP AS 1 2069925151UL
PCB
J011 CRIMP AS CRIMP AS 1 2069925266UL
PCB
JL6402A WIRE HOL NSCT-3P874 1 25051087
PCB
JL6402B WIRE HOL NSCT-3P874 1 25051087
PCB
JL6803A WIRE HOL NSCT-6P897 1 25051110
PCB
JL6804A WIRE HOL NSCT-6P897 1 25051110
PCB
JL6805A WIRE HOL NSCT-4P895 1 25051108
PCB
JL6952A WIRE HOL NSCT-5P896 1 25051109
PCB
JL6952B WIRE HOL NSCT-5P896 1 25051109
PACKING PROCEDURES PARTS LIST
<Notes>
<502>:TX-SR502 <DC> : Canadian model
<502E>:TX-SR502E(European model) <DD> : American model
<8250>:TX-SR8250(Chinese model) <GK> : Korean model
(B) : Black model <GQ> : Hong kong model
(S) : Silver model <GR> : Chinese model
(G) : Golden model <PA> : Australian model
<PT> : Asian model (230-240V)
<WT> : World wide model
REF. NO. NAME DESCRIPTION Q'TY PART NO REMARKS
PKG
A601 PAD AS 1 29092044A
<502>,<502E>,<8250>
PKG
A603 POLY BAG POLY BAG(850 x 650) 1 29100034-1A
PKG
A604 SHEET
For Remote Controller
1 29095969
<502>,<502E>,<8250>
PKG
A605 TAPE NITTO NO.29 3 29110149
PKG
A607 PP TAPE W48 OPP TAPE 1 29110148
<502>,<502E>,<8250>
PKG
A620 POLY BAG 350 x 250 1 29100097-1A
<502>,<8250>
PKG
A620 POLY BAG 250 x 250 x W300 1 29100218
<520>,<502E>
PKG
A624 LABEL SP CABLE 1 29363059A
<502>,<502E>,<8250>
PKG
A701 CARTON --- 1 29054150
<502 DD>(B)
PKG
A701 CARTON --- 1 29054152
<502E>(B)
PKG
A701 CARTON --- 1 29054153
<502E>(S)
PKG
A701 CARTON --- 1 29054154
<502 DC,PA,WT> (B)
PKG
A701 CARTON --- 1 29054155
<502 DC,PA,WT> (S)
PKG
A701 CARTON --- 1 29054156
<502 GQ,PT,GK,WT> (G)
PKG
A701 CARTON --- 1 29054157
<502 GR> (G)
PKG
A701 CARTON --- 1 29054158
<8250>
PKG
A701 CARTON --- 1 29054180
<502 GR> (S)
PKG
A702 POLY BAG 250 x 250 x W300 1 29100218
<502 GR> (S)
PKG
A703 UPC LABEL --- 1 29363632
<502 DD,DC> (B)
PKG
A703 UPC LABEL --- 1 29363633
<502 DC> (S)
PKG
A703 EAN LABEL --- 1 29363636
<502E> (B)
PKG
A703 EAN LABEL --- 1 29363637
<502E> (S)
PKG
A703 EAN LABEL --- 1 29363638
<502 PA,WT> (B)
PKG
A703 EAN LABEL --- 1 29363639
<502 PA,GR,WT> (S)
PKG
A703 EAN LABEL --- 1 29363640
<502> (G)
PKG
A703 EAN LABEL --- 1 29363681
<8250> (G)
PKG
A801 INS MANUAL En(TX-SR502/8250) 1 29343629C
<502>,<502E>,<8250>
PKG
A802 INS MANUAL U2FrEs(TX-SR502) 1 29343630A
<502E>
TX-SR502/E/8250/HT-R520
