Onkyo HT-R520 Service Manual

2/40 PAGE
EXP
A401 REAR PANEL --- 1 27123242A
<502 DD,DC>
EXP
A401 REAR PANEL --- 1 27123243
<502E>
EXP
A401 REAR PANEL --- 1 27123244
<502 GK>
EXP
A401 REAR PANEL --- 1 27123245
<502 WT>
EXP
A401 REAR PANEL --- 1 27123246
<502 GR>
EXP
A401 REAR PANEL --- 1 27123247
<502 PA>
EXP
A401 REAR PANEL --- 1 27123249A
<520>
EXP
A401 REAR PANEL --- 1 27123250
<8250>
EXP
A401 REAR PANEL --- 1 27123251
<502 GQ>
EXP
A401 REAR PANEL --- 1 27123290
<502 PT>
EXP
A402 SCREW 3TTB+8B(BC) 28 838430088
<502E>
EXP
A402 SCREW 3TTB+8B(BC) 29 838430088
<502 GK,GR>
EXP
A402 SCREW 3TTB+8B(BC) 31 838430088
<502 DC,DD,PA,PT>,<502E>
EXP
A402 SCREW 3TTB+8B(BC) 32 838430088
<502 GQ,WT>,<8250
EXP
A403 HOLDER (OUTLET) 1 27191143
<502 GR>,<8250>
EXP
A407 F PANEL --- 1 27212630
<502 DD,DC>(B)
EXP
A407 F PANEL --- 1 27212631
<502 DC>(S)
EXP
A407 F PANEL --- 1 27212632
<502E>(B)
EXP
A407 F PANEL --- 1 27212633
<502E>(S)
EXP
A407 F PANEL --- 1 27212634
<502 GR,PA,WT>(S)
EXP
A407 F PANEL --- 1 27212635
<502 PA,WT>(B)
EXP
A407 F PANEL --- 1 27212636
<502>(G)
EXP
A407 F PANEL --- 1 27212638
<520>(B)
EXP
A407 F PANEL --- 1 27212639
<520>(S)
EXP
A407 F PANEL --- 1 27212640
<8250>
EXP
A409 BADGE BADGE 1 28135244
(B)
EXP
A409 BADGE BADGE 1 28135245
(S),(G)
EXP
A413 LABEL (PT) 1 29363379-1
<502>,<502E>,<8250>
EXP
A420 FACET --- 1 28198987
<502 PA,PT,GR,GQ,WT>
EXP
A420 FACET --- 1 28198987
<502E>,<8250>
EXP
A430 LABEL HOOKUP-ONKYO 1 29363194
<502 DD>,<520>
EXP
F901 FUSE 6.3A-UL/T-237 1 252166
! <502 DD,DC,WT>
EXP
F901 or FUSE 6.3A-T/UL-ST2 (1) 252260
! <502 DD,DC,WT>
EXP
F901 FUSE 8A-UL 1 252198
!<520>
EXP
F901 or FUSE 8A-T/UL-ST2 (1) 252261
!<520>
EXP
F902 FUSE 3.15A-SE-EAK 1 252076
! <502 PA,PT,WT,GR,GK,GQ>
EXP
F902 or FUSE 3.15A-SE-TL250V (1) 252242
! <502 PA,PT,WT,GR,GK,GQ>
EXP
F902 or FUSE 3.15A-SE-TL250V (1) 252276
! <502 PA,PT,WT,GR,GK,GQ>
EXP
F902 FUSE 3.15A-SE-EAK 1 252076
! <502E>,<8250>
EXP
F902 or FUSE 3.15A-SE-TL250V (1) 252242
! <502E>,<8250>
EXP
F902 or FUSE 3.15A-SE-TL250V (1) 252276
! <502E>,<8250>
EXP
F903 FUSE 2.5A-SE-EAK 1 252075
! <502 PA,PT,WT,GR,GK,GQ>
EXP
F903 or FUSE 2.5A-SE-TL250V (1) 252241
! <502 PA,PT,WT,GR,GK,GQ>
EXP
F903 or FUSE 2.5A-SE-TL250V (1) 252275
! <502 PA,PT,WT,GR,GK,GQ>
EXP
F903 FUSE 2.5A-SE-EAK 1 252075
! <520E>,<8250>
EXP
F903 or FUSE 2.5A-SE-TL250V (1) 252241
! <520E>,<8250>
EXP
F903 or FUSE 2.5A-SE-TL250V (1) 252275
! <520E>,<8250>
EXP
F903 FUSE 5A-UL/T-237 1 252164
! <502 DD, DC>,<520>
EXP
F903 or FUSE 5A-T/UL-ST2 (1) 252258
! <502 DD, DC>,<520>
EXP
F6901 FUSE 10A-UL 1 252199
! <502 DD, DC>,<520>
EXP
F6901 FUSE 10A-EAK 1 252100
! <502 PA,WT,GR,PT,GK,GQ>
EXP
F6901 or FUSE 10A-TL250V (1) 252307
! <502 PA,WT,GR,PT,GK,GQ>
EXP
F6901 FUSE 10A-EAK 1 252100
! <502E>
EXP
F6901 or FUSE 10A-TL250V (1) 252307
! <502E>
EXP
F6902 FUSE 10A-UL 1 252199
! <502 DD, DC>,<520>
EXP
F6902 FUSE 10A-EAK 1 252100
! <502 PA,WT,GR,PT,GK,GQ>
EXP
F6902 or FUSE 10A-TL250V (1) 252307
! <502 PA,WT,GR,PT,GK,GQ>
EXP
F6902 FUSE 10A-EAK 1 252100
! <502E>
EXP
F6902 or FUSE 10A-TL250V (1) 252307
! <502E>
EXP
P101 FFC NCFC7-151512 1 2047151512
EXP
P306B TAPE TAPE(CLOTH-16U) (1) 29110083
EXP
P7502 FFC NCFC5-102012 1 2045102012
EXP
P7503 FFC NCFC7-081012 1 2047081012
EXP
P800 WIRE TIE BINDER UL 10 260208
EXP
P901 AC CORD AS-BS 1 253198HIT
! <502 GQ>
EXP
P901 AC CORD AS-CCC 1 253377LTK
! <502 GR>,<8250>
EXP
P901 or AC CORD AS-CCC ( 1) 253355VOL
! <502 GR>,<8250>
EXP
P901 AC CORD AS-CEE-2 1 253233KAW
! <502 WT,PT,GK>,<502E>
EXP
P901 or AC CORD AS-CEE-2 ( 1) 253306VOL
! <502 WT,PT,GK>,<502E>
EXP
P901 or AC CORD AS-CEE-2 ( 1) 253374LTK
! <502 WT,PT,GK>,<502E>
EXP
P901 AC CORD AS-SAA 1 253197HIT
! <502 PA>
EXP
P901 AC CORD AS-UC-2 1 253368LTK
! <502 DC,DD>,<520>
EXP
P901 or AC CORD AS-UC-2 ( 1) 253332HIT
! <502 DC,DD>,<520>
