Onkyo HT-R520 Service Manual

9/40 PAGE
PCB
L802 EMIFIL BK1608LM182-T 1 230958R1
PCB
L803 CHOKE COIL NCH-1471 1 231237M022R2
PCB
L803 or CHOKE COIL NCH-1587-022K ( 1) 233533K022R2
PCB
L7001 CHOKE COIL NCH-1479 1 231237K470R2
PCB
L7002 CHOKE COIL NCH-1471 1 231237M022R2
PCB
L7002 or CHOKE COIL NCH-1587-022K ( 1) 233533K022R2
PCB
L7301 CHOKE COIL NCH-1471 1 231237M022R2
<520>
PCB
L7301 or CHOKE COIL NCH-1587-022K ( 1) 233533K022R2
<520>
PCB
L7302 EMIFIL BK1608LL241-T 1 230959R1
PCB
L7501 CHOKE COIL NCH-1471 1 231237M022R2
<502 DD, DC>,<520>
PCB
L7501 or CHOKE COIL NCH-1587-022K ( 1) 233533K022R2
<502 DD, DC>,<520>
PCB
L7502 CHOKE COIL NCH-1471 1 231237M022R2
<502 DD, DC>,<520>
PCB
L7502 or CHOKE COIL NCH-1587-022K ( 1) 233533K022R2
<502 DD, DC>,<520>
PCB
L7503 CHOKE COIL NCH-1471 1 231237M022R2
<502 DD, DC>,<520>
PCB
L7503 or CHOKE COIL NCH-1587-022K ( 1) 233533K022R2
<502 DD, DC>,<520>
PCB
L7504 CHOKE COIL NCH-1477 1 231237K220R2
PCB
L7505 CHOKE COIL NCH-1477 1 231237K220R2
PCB
X181 XTL AF6146CG 1 3010203
<502E>
PCB
X7001 CERA LOCK CSTCE12M5G52-R0 1 3010361R2
PCB
X7501 CERA LOCK CST5.00MGW 1 3010242
PCB
X781 CERA LOCK CSTCV12.2MTJ0C4 1 3010324R2
PCB
C101 ELECT C CE04W50V3.3M(SC) 1 394780337
PCB
C101 or VR C CE04W50V-3.3M(VR) ( 1) 394680337
PCB
C103 ELECT C CE04W50V3.3M(SC) 1 394780337
PCB
C103 or VR C CE04W50V-3.3M(VR) ( 1) 394680337
PCB
C104 C-CERA C CC725CH1H-101J1 1 342101014R1
PCB
C106 C-CERA C CC725CH1H-101J1 1 342101014R1
PCB
C109 ELECT C CE04W50V100M(SC) 1 394781017
PCB
C109 or VR C CE04W50V-100M(VR) ( 1) 394681017
PCB
C181 ELECT C CE04W50V2.2M(SC) 1 394780227
<502E>
PCB
C181 or VR C CE04W50V-2.2M(VR) ( 1) 394680227
<502E>
PCB
C182 C-CERA C CK725B1H-103K1 1 332101035R1
<502E>
PCB
C183 C-CERA C CC725CH1H-561J1 1 342105614R1
<502E>
PCB
C184 ELECT C CE04W16V47M(SC) 1 394744707
<502E>
PCB
C184 or VR C CE04W16V-47M(VR) ( 1) 394644707
<502E>
PCB
C185 C-CERA C CK725F1E-104Z1 1 332161040R1
<502E>
PCB
C186 C-CERA C CC725CH1H-330J1 1 342103304R1
<502E>
PCB
C187 C-CERA C CC725CH1H-330J1 1 342103304R1
<502E>
PCB
C253 C-CERA C CK725F1E-104Z1 1 332161040R1
PCB
C261 C-CERA C CC725CH1H-101J1 1 342101014R1
<502 DD,DC>,<520>
PCB
C261 C-CERA C CC725CH1H-471J1 1 342104714R1
<502 PA,GK,GQ,GR,PT,WT>
PCB
C261 C-CERA C CC725CH1H-471J1 1 342104714R1
<502E>,<8250>
PCB
C262 C-CERA C CC725CH1H-101J1 1 342101014R1
<502 DD,DC>,<520>
PCB
C262 C-CERA C CC725CH1H-471J1 1 342104714R1
<502 PA,GK,GQ,GR,PT,WT>
PCB
C262 C-CERA C CC725CH1H-471J1 1 342104714R1
<502E>,<8250>
PCB
C263 C-CERA C CK725F1E-104Z1 1 332161040R1
PCB
C300 TF C ECQ-B50V-101K 1 374721015
<502 DD, DC>,<520>
PCB
C300 TF C ECQ-B50V-471J 1 374724714
<502 PA,GK,GQ,GR,PT,WT>
PCB
C300 TF C ECQ-B50V-471J 1 374724714
<502E>,<8250>
PCB
C301 TF C ECQ-B50V-101K 1 374721015
<502 DD, DC>,<520>
PCB
C301 TF C ECQ-B50V-471J 1 374724714
<502 PA,GK,GQ,GR,PT,WT>
PCB
C301 TF C ECQ-B50V-471J 1 374724714
<502E>,<8250>
PCB
C302 C-CERA C CC725CH1H-101J1 1 342101014R1
PCB
C303 C-CERA C CC725CH1H-101J1 1 342101014R1
PCB
C304 C-CERA C CC725CH1H-101J1 1 342101014R1
<502 DD, DC>,<520>
PCB
C304 C-CERA C CC725CH1H-471J1 1 342104714R1
<502 PA,GK,GQ,GR,PT,WT>
PCB
C304 C-CERA C CC725CH1H-471J1 1 342104714R1
<502E>,<8250>
PCB
C305 C-CERA C CC725CH1H-101J1 1 342101014R1
<502 DD, DC>,<520>
PCB
C305 C-CERA C CC725CH1H-471J1 1 342104714R1
<502 PA,GK,GQ,GR,PT,WT>
PCB
C305 C-CERA C CC725CH1H-471J1 1 342104714R1
<502E>,<8250>
PCB
C308 CERA C CK45F50V-103Z 1 335621030
PCB
C310 C-CERA C CC725CH1H-101J1 1 342101014R1
<502 DD, DC>,<520>
PCB
C310 C-CERA C CC725CH1H-471J1 1 342104714R1
<502 PA,GK,GQ,GR,PT,WT>
PCB
C310 C-CERA C CC725CH1H-471J1 1 342104714R1
<502E>,<8250>
PCB
C311 C-CERA C CC725CH1H-101J1 1 342101014R1
<502 DD, DC><520>
PCB
C311 C-CERA C CC725CH1H-471J1 1 342104714R1
<502 PA,GK,GQ,GR,PT,WT>
PCB
C311 C-CERA C CC725CH1H-471J1 1 342104714R1
<502E><8250>
PCB
C312 C-CERA C CC725CH1H-101J1 1 342101014R1
PCB
C313 C-CERA C CC725CH1H-101J1 1 342101014R1
PCB
C314 C-CERA C CC725CH1H-101J1 1 342101014R1
<502 DD, DC>,<520>
PCB
C314 C-CERA C CC725CH1H-471J1 1 342104714R1
<502 PA,GK,GQ,GR,PT,WT>
PCB
C314 C-CERA C CC725CH1H-471J1 1 342104714R1
<502E><8250>
PCB
C315 C-CERA C CC725CH1H-101J1 1 342101014R1
<502 DD, DC>,<,520>
