Onkyo HT-R520 - Page 84

8/40 PAGE
PCB
Q7504 or TR RN2403 ( 1) 2214540R2
PCB
Q7506 TR KRC102S 1 2216190R2
PCB
Q7506 or TR RN1402 ( 1) 2214470R2
PCB
Q7507 TR KRC102S 1 2216190R2
<502 PA, PT, GK, GQ, GR>
PCB
Q7507 TR KRC102S 1 2216190R2
<502E>,<8250>
PCB
Q9501 TR 2SA1015-GR 1 2211455
PCB
D109 ZENER D UDZS5.1B 1 224550510R2
PCB
D109 or ZENER D UDZ5.1B ( 1) 224490510R2
PCB
D109 or ZENER D HZU5.1B ( 1) 224660514R2
PCB
D801 C-DIODE 1SS352 1 223234R2
PCB
D801 or C-DIODE 1SS355 ( 1) 223269R2
PCB
D802 C-DIODE 1SS352 1 223234R2
PCB
D802 or C-DIODE 1SS355 ( 1) 223269R2
PCB
D805 C-DIODE 1SS352 1 223234R2
PCB
D805 or C-DIODE 1SS355 ( 1) 223269R2
PCB
D806 C-DIODE 1SS352 1 223234R2
PCB
D806 or C-DIODE 1SS355 ( 1) 223269R2
PCB
D7001 C-DIODE 1SS352 1 223234R2
PCB
D7001 or C-DIODE 1SS355 ( 1) 223269R2
PCB
D7002 C-DIODE 1SS352 1 223234R2
PCB
D7002 or C-DIODE 1SS355 ( 1) 223269R2
PCB
D7003 C-DIODE 1SS352 1 223234R2
PCB
D7003 or C-DIODE 1SS355 ( 1) 223269R2
PCB
D7004 C-DIODE 1SS352 1 223234R2
PCB
D7004 or C-DIODE 1SS355 ( 1) 223269R2
PCB
D7501 ZENER D UDZS8.2B 1 224550820R2
PCB
D7501 or ZENER D UDZ8.2B ( 1) 224490820R2
PCB
D7501 or ZENER D HZU8.2B ( 1) 224660824R2
PCB
D7502 ZENER D UDZS5.1B 1 224550510R2
PCB
D7502 or ZENER D UDZ5.1B ( 1) 224490510R2
PCB
D7502 or ZENER D HZU5.1B ( 1) 224660514R2
PCB
D7503 C-DIODE 1SS355 1 223269R2
PCB
D7503 or C-DIODE 1SS352 ( 1) 223234R2
PCB
D7504 LED SEL2E10C 1 225374
<502 PA,GK,GQ,GR,PT,WT>
PCB
D7504 LED SEL2E10C 1 225374
<502E>,<8250>
PCB
D7505 LED SLR-56VRTB7 1 225431
PCB
D7505 or LED SEL4110R ( 1) 225290
PCB
D7507 C-DIODE 1SS352 1 223234R2
PCB
D7507 or C-DIODE 1SS355 ( 1) 223269R2
PCB
D7702 ZENER D UDZS6.2B 1 224550620R2
PCB
D7702 or ZENER D UDZ6.2B ( 1) 224490620R2
PCB
D7702 or ZENER D HZU6.2B ( 1) 224660624R2
PCB
D9502 DIODE RL1N4003 1 22380260
PCB
D9502 or DIODE GP104003E ( 1) 22380035
PCB
D9503 DIODE RL1N4003 1 22380260
PCB
D9503 or DIODE GP104003E ( 1) 22380035
PCB
D9504 DIODE RL1N4003 1 22380260
PCB
D9504 or DIODE GP104003E ( 1) 22380035
PCB
D9505 DIODE RL1N4003 1 22380260
PCB
D9505 or DIODE GP104003E ( 1) 22380035
PCB
D9506 DIODE RL1N4003 1 22380260
PCB
D9506 or DIODE GP104003E ( 1) 22380035
PCB
D9507 DIODE RL1N4003 1 22380260
PCB
D9507 or DIODE GP104003E ( 1) 22380035
PCB
D9508 ZENER D UDZS27B 1 224552700R2
PCB
D9508 or ZENER D UDZ27B ( 1) 224492700R2
PCB
D9508 or ZENER D HZU27B ( 1) 224662704R2
PCB
D9513 DIODE D2SB80A 1 22380341F
PCB
L181 CHOKE COIL NCH-1477 1 231237K220R2
<502E>
PCB
L701 CHOKE COIL NCH-1471 1 231237M022R2
PCB
L701 or CHOKE COIL NCH-1587-022K ( 1) 233533K022R2
PCB
L702 CHOKE COIL NCH-1471 1 231237M022R2
PCB
L702 or CHOKE COIL NCH-1587-022K ( 1) 233533K022R2
PCB
L703 CHOKE COIL NCH-1477 1 231237K220R2
PCB
L751 CHOKE COIL NCH-1471 1 231237M022R2
PCB
L751 or CHOKE COIL NCH-1587-022K ( 1) 233533K022R2
PCB
L781 EMIFIL BK1608LM182-T 1 230958R1
PCB
L782 EMIFIL BK1608LM182-T 1 230958R1
PCB
L783 CHOKE COIL NCH-1477 1 231237K220R2
PCB
L800 CHOKE COIL NCH-1471 1 231237M022R2
PCB
L800 or CHOKE COIL NCH-1587-022K ( 1) 233533K022R2
PCB
L801 CHOKE COIL NCH-1471 1 231237M022R2
PCB
L801 or CHOKE COIL NCH-1587-022K ( 1) 233533K022R2
