Onkyo HT-R520 Service Manual

7/40 PAGE
PCB
Q305 IC NJM4565M-D 1 22241383R2
PCB
Q305 or IC MPC4570G2-T1(MST) ( 1) 22240489R1NE
PCB
Q305 or IC NJM4565M ( 1) 22240581R2
PCB
Q305 or IC HA17558A ( 1) 22242126R2
PCB
Q306 TR RN2402 1 2214530R2
PCB
Q306 or TR KRA102S ( 1) 2216220R2
PCB
Q307 TR RN1441 1 2215410R2
PCB
Q308 TR RN1441 1 2215410R2
PCB
Q312 TR RN1441 1 2215410R2
PCB
Q313 TR RN1441 1 2215410R2
PCB
Q321 IC(REGULATOR) 78L07(SMT) 1 222780073R2
PCB
Q322 IC(REGULATOR) 79L07(SMT) 1 222790073R2
PCB
Q701 IC CS494003CQZ 1 22242039R3
PCB
Q702 IC MX29LV040(TXSR502) 1 22242119R3
PCB
Q703 IC TC7WU04FU 1 22240935R2
PCB
Q800 IC AK4588VQ 1 22242118R3
PCB
Q801 IC NJM4565M-D 1 22241383R2
PCB
Q801 or IC MPC4570G2-T1(MST) ( 1) 22240489R1NE
PCB
Q801 or IC NJM4565M ( 1) 22240581R2
PCB
Q801 or IC HA17558A ( 1) 22242126R2
PCB
Q802 IC NJM4565M-D 1 22241383R2
PCB
Q802 or IC MPC4570G2-T1(MST) ( 1) 22240489R1NE
PCB
Q802 or IC NJM4565M ( 1) 22240581R2
PCB
Q802 or IC HA17558A ( 1) 22242126R2
PCB
Q803 IC NJM4565M-D 1 22241383R2
PCB
Q803 or IC MPC4570G2-T1(MST) ( 1) 22240489R1NE
PCB
Q803 or IC NJM4565M ( 1) 22240581R2
PCB
Q803 or IC HA17558A ( 1) 22242126R2
PCB
Q804 IC NJM4565M-D 1 22241383R2
PCB
Q804 or IC MPC4570G2-T1(MST) ( 1) 22240489R1NE
PCB
Q804 or IC NJM4565M ( 1) 22240581R2
PCB
Q804 or IC HA17558A ( 1) 22242126R2
PCB
Q6402 IC(REGURATOR) 7812HF(TA7812S) 1 222780124TOS
PCB
Q6402 or IC(REGULATOR) 78M12HF ( 1) 222780125
PCB
Q6402A SCREW 3P+10FN(BC) 1 82143010
PCB
Q6402B HEAT SINK RAD-183 1 27160526
PCB
Q6402C TAPE TAPE(CLOTH-16U) 1 29110083
PCB
Q6403 IC(REGURATOR) 79012HF(TA79012S) 1 222790124TOS
PCB
Q6403 or IC(REGULATOR) 79M12HF ( 1) 222790125
PCB
Q6405 IC(REGURATOR) 7812HF(TA7812S) 1 222780124TOS
PCB
Q6405 or IC(REGULATOR) 78M12HF ( 1) 222780125
PCB
Q6405A SCREW 3P+10FN(BC) 1 82143010
PCB
Q6406 IC(REGURATOR) TA4805S 1 222780059TOS
PCB
Q6406 or IC(REGULATOR) MPC2905HF ( 1) 22278005DNE
PCB
Q6406A SCREW 3P+10FN(BC) 1 82143010
PCB
Q6407 TR 2SB1068-K 1 2212853
<502 PA, PT, GK, GQ, GR>
PCB
Q6407 TR 2SB1068-K 1 2212853
<502E>,<8250>
PCB
Q6408 TR RN1402 1 2214470R2
<502 PA, PT, GK, GQ, GR>
PCB
Q6408 or TR KRC102S ( 1) 2216190R2
<502 PA, PT, GK, GQ, GR>
PCB
Q6408 or TR DTC114EKA ( 1) 2216250R2
<502 PA, PT, GK, GQ, GR>
PCB
Q6408 TR RN1402 1 2214470R2
<502E>,<8250>
PCB
Q6408 or TR KRC102S ( 1) 2216190R2
<502E>,<8250>
PCB
Q6408 or TR DTC114EKA ( 1) 2216250R2
<502E>,<8250>
PCB
Q7001 TR RN1404 1 2214490R2
PCB
Q7001 or TR KRC104S ( 1) 2216210R2
PCB
Q7002 IC TC74VHC541FT 1 22274541ER2TO
PCB
Q7003 IC TC74HCT7007AF 1 222740077R2TO
PCB
Q7004 IC BA33C25FP 1 22241778R2
PCB
Q7004A HEAT SINK RAD-202 1 27160552
PCB
Q7006 TR RN1404 1 2214490R2
PCB
Q7006 or TR KRC104S ( 1) 2216210R2
PCB
Q7007 TR RN1404 1 2214490R2
PCB
Q7007 or TR KRC104S ( 1) 2216210R2
PCB
Q7008 IC MPD784225GC-253-8BT 1 22242167R3
PCB
Q7301 IC IC42S16100 1 22242123R3
<520>
PCB
Q7301 or IC IC42S16100 ( 1) 22242123R2
<520>
PCB
Q7301 or IC K4S161622H-UC60 ( 1) 22242152R2
<520>
PCB
Q7501 FL TUBE HNA-16SM10T 1 212249A
PCB
Q7501A HOLDER (FL) 1 27191222
PCB
Q7502 IC MPD780232GC-096-8BT 1 22242116R3
PCB
Q7503 TR KTC3875-GR 1 2216175R2
PCB
Q7503 or TR 2SC2712-GR ( 1) 2213145R2
PCB
Q7504 TR KRA103S 1 2216230R2
