Onkyo HT-R520 Service Manual

12/40 PAGE
PCB
C855 VX C CE04W16V-10M(VX) 1 393341007
PCB
C856 VX C CE04W16V-10M(VX) 1 393341007
PCB
C6401 TF C ECQ-V50V-104J 1 374721044
PCB
C6403 C-CERA C CK725F1H-223Z1 1 332152230R1
PCB
C6404 ELECT C CE04W16V10M(SC) 1 394741007
PCB
C6404 or VR C CE04W16V-10M(VR) ( 1) 394641007
PCB
C6405 C-CERA C CK725F1H-223Z1 1 332152230R1
PCB
C6406 ELECT C CE04W16V10M(SC) 1 394741007
PCB
C6406 or VR C CE04W16V-10M(VR) ( 1) 394641007
PCB
C6409 C-CERA C CK725F1H-223Z1 1 332152230R1
PCB
C6410 ELECT C CE04W16V10M(SC) 1 394741007
PCB
C6410 or VR C CE04W16V-10M(VR) ( 1) 394641007
PCB
C6411 C-CERA C CK725F1H-223Z1 1 332152230R1
PCB
C6412 ELECT C CE04W16V330M(SC) 1 394743317
PCB
C6412 or VX C CE04W16V-330M(VX) ( 1) 393343317
PCB
C6412 or VR C CE04W16V-330M(VR) ( 1) 394643317
PCB
C6421 C-CERA C CK725F1E-104Z1 1 332161040R1
PCB
C7001 EDL C DX-5R5L104 1 3000078
PCB
C7001 or EDL C FMC0H104Z ( 1) 3000120
PCB
C7001 or EDL C SCDA5R5104A ( 1) 3000121
PCB
C7002 ELECT C CE04W6.3V100M(SC) 1 394721017
PCB
C7002 or VR C CE04W6.3V-100M(VR) ( 1) 394621017
PCB
C7003 C-CERA C CK725F1E-104Z1 1 332161040R1
PCB
C7004 ELECT C CE04W50V1.0M(SC) 1 394780107
PCB
C7004 or VR C CE04W50V-1M(VR) ( 1) 394680107
PCB
C7005 ELECT C CE04W6.3V100M(SC) 1 394721017
PCB
C7005 or VR C CE04W6.3V-100M(VR) ( 1) 394621017
PCB
C7006 C-CERA C CK725F1E-104Z1 1 332161040R1
PCB
C7007 C-CERA C CK725F1E-104Z1 1 332161040R1
PCB
C7008 C-CERA C CK725F1E-104Z1 1 332161040R1
PCB
C7009 C-CERA C CK725F1E-104Z1 1 332161040R1
PCB
C7010 C-CERA C CK725F1E-104Z1 1 332161040R1
PCB
C7011 ELECT C CE04W16V47M(SC) 1 394744707
PCB
C7011 or VR C CE04W16V-47M(VR) ( 1) 394644707
PCB
C7012 ELECT C CE04W16V47M(SC) 1 394744707
PCB
C7012 or VR C CE04W16V-47M(VR) ( 1) 394644707
PCB
C7015 ELECT C CE04W16V47M(SC) 1 394744707
PCB
C7015 or VR C CE04W16V-47M(VR) ( 1) 394644707
PCB
C7020 C-CERA C CK725F1E-104Z1 1 332161040R1
PCB
C7021 C-CERA C CK725F1E-104Z1 1 332161040R1
PCB
C7301 C-CERA C CK725F1E-104Z1 1 332161040R1
<520>
PCB
C7302 C-CERA C CK725F1E-104Z1 1 332161040R1
<520>
PCB
C7303 C-CERA C CK725F1E-104Z1 1 332161040R1
<520>
PCB
C7304 C-CERA C CK725F1E-104Z1 1 332161040R1
<520>
PCB
C7305 C-CERA C CK725F1E-104Z1 1 332161040R1
<520>
PCB
C7306 C-CERA C CK725F1E-104Z1 1 332161040R1
<520>
PCB
C7307 ELECT C
CE04W6.3V100M(SC)
1 394721017
<520>
PCB
C7307 or VR C
CE04W6.3V-100M(VR)
( 1) 394621017
<520>
PCB
C7501 C-CERA C CK725F1E-104Z1 1 332161040R1
PCB
C7502 ELECT C CE04W50V-33M 1 355783309
PCB
C7503 C-CERA C CK725F1E-104Z1 1 332161040R1
PCB
C7504 C-CERA C CK725F1H-473Z1 1 332154730R1
PCB
C7505 C-CERA C CK725F1H-473Z1 1 332154730R1
PCB
C7506 C-CERA C CK725F1E-104Z1 1 332161040R1
PCB
C7507 C-CERA C CK725F1E-104Z1 1 332161040R1
PCB
C7508 C-CERA C CC725CH1E-102J1 1 342111024R1
PCB
C7509 C-CERA C CC725CH1E-102J1 1 342111024R1
PCB
C7510 C-CERA C CC725CH1E-102J1 1 342111024R1
PCB
C7511 C-CERA C CC725CH1E-102J1 1 342111024R1
PCB
C7513 C-CERA C CK725F1E-104Z1 1 332161040R1
PCB
C7514 ELECT C CE04W6.3V-100M(S) 1 353721019
PCB
C7515 C-CERA C CK725F1E-104Z1 1 332161040R1
PCB
C7516 C-CERA C CK725F1E-104Z1 1 332161040R1
PCB
C7517 C-CERA C CC725CH1E-102J1 1 342111024R1
PCB
C7518 C-CERA C CC725CH1E-102J1 1 342111024R1
PCB
C7519 C-CERA C CC725CH1E-102J1 1 342111024R1
PCB
C7520 C-CERA C CC725CH1E-102J1 1 342111024R1
PCB
C7521 ELECT C CE04W6.3V-220M 1 355722219
PCB
C7522 C-CERA C CC725CH1H-101J1 1 342101014R1
PCB
C7523 C-CERA C CC725CH1E-102J1 1 342111024R1
PCB
C9501 TF C ECQ-V50V-104J 1 374721044
PCB
C9503 TF C ECQ-V50V-104J 1 374721044
PCB
C9505 ELECT C CE04W35V2200M(SC) 1 394762227S
