Onkyo HT-R520 Service Manual

18/40 PAGE
PCB
R7516 C-CARBON R RN72K1J-103JE 1 435031034R1
PCB
R7517 C-CARBON R RN72K1J-102JE 1 435031024R1
PCB
R7518 C-CARBON R RN72K1J-104JE 1 435031044R1
PCB
R7519 C-CARBON R RN72K1J-104JE 1 435031044R1
PCB
R7520 C-CARBON R RN72K1J-272JE 1 435032724R1
PCB
R7521 C-CARBON R RN72K1J-272JE 1 435032724R1
PCB
R7522 C-CARBON R RN72K1J-272JE 1 435032724R1
PCB
R7523 C-CARBON R RN72K1J-272JE 1 435032724R1
PCB
R7524 C-CARBON R RN72K1J-102JE 1 435031024R1
PCB
R7526 C-CARBON R RN72K1J-103JE 1 435031034R1
PCB
R7527 C-CARBON R RN72K1J-103JE 1 435031034R1
PCB
R7528 C-CARBON R RN72K1J-561JE 1 435035614R1
PCB
R7529 C-CARBON R RN72K1J-561JE 1 435035614R1
PCB
R7530 C-CARBON R RN72K1J-102JE 1 435031024R1
PCB
R7531 C-CARBON R RN72K1J-391JE 1 435033914R1
PCB
R7532 C-CARBON R RN72K1J-103JE 1 435031034R1
PCB
R7591 C-CARBON R RN72K1J-000JE 1 435030004R1
<502 PA,PT,GK,GQ,GR,WT>
PCB
R7591 C-CARBON R RN72K1J-000JE 1 435030004R1
<502E>,<8250>
PCB
R7592 C-CARBON R RN72K1J-000JE 1 435030004R1
<502 PA,PT,GK,GQ,GR,WT>
PCB
R7592 C-CARBON R RN72K1J-000JE 1 435030004R1
<502E>,<8250>
PCB
R7593 C-CARBON R RN72K1J-000JE 1 435030004R1
<502 PA,PT,GK,GQ,GR,WT>
PCB
R7593 C-CARBON R RN72K1J-000JE 1 435030004R1
<502E>,<8250>
PCB
R7611 C-CARBON R RN72K1J-331JE 1 435033314R1
PCB
R7612 C-CARBON R RN72K1J-471JE 1 435034714R1
PCB
R7613 C-CARBON R RN72K1J-561JE 1 435035614R1
PCB
R7615 C-CARBON R RN72K1J-821JE 1 435038214R1
PCB
R7616 C-CARBON R RN72K1J-122JE 1 435031224R1
PCB
R7617 C-CARBON R RN72K1J-222JE 1 435032224R1
PCB
R7621 C-CARBON R RN72K1J-331JE 1 435033314R1
PCB
R7622 C-CARBON R RN72K1J-471JE 1 435034714R1
PCB
R7623 C-CARBON R RN72K1J-561JE 1 435035614R1
PCB
R7624 C-CARBON R RN72K1J-821JE 1 435038214R1
PCB
R7625 C-CARBON R RN72K1J-122JE 1 435031224R1
PCB
R7626 C-CARBON R RN72K1J-222JE 1 435032224R1
PCB
R7631 C-CARBON R RN72K1J-331JE 1 435033314R1
PCB
R7632 C-CARBON R RN72K1J-471JE 1 435034714R1
PCB
R7633 C-CARBON R RN72K1J-561JE 1 435035614R1
PCB
R7634 C-CARBON R RN72K1J-821JE 1 435038214R1
PCB
R7635 C-CARBON R RN72K1J-122JE 1 435031224R1
PCB
R7636 C-CARBON R RN72K1J-222JE 1 435032224R1
PCB
R7637 C-CARBON R RN72K1J-392JE 1 435033924R1
PCB
R7641 C-CARBON R RN72K1J-331JE 1 435033314R1
PCB
R7642 C-CARBON R RN72K1J-471JE 1 435034714R1
PCB
R7643 C-CARBON R RN72K1J-561JE 1 435035614R1
PCB
R7644 C-CARBON R RN72K1J-821JE 1 435038214R1
PCB
R7645 C-CARBON R RN72K1J-122JE 1 435031224R1
PCB
R7646 C-CARBON R RN72K1J-222JE 1 435032224R1
PCB
R7839 C-CARBON R RN72K1J-223JE 1 435032234R1
PCB
R9506 METAL O R RS1/2WBJ-22 1 443522204
PCB
R9507 C-CARBON R RN72K1J-153JE 1 435031534R1
PCB
R9508 C-CARBON R RN72K1J-153JE 1 435031534R1
PCB
R9509 C-CARBON R RN72K1J-104JE 1 435031044R1
PCB
E300 RETAINER KANAGU 1 27141059
PCB
E301 RETAINER (S) 1 27141931
PCB
E7501 RETAINER KANAGU 1 27141059
PCB
P101 SOCKET NSCT-15P2108 1 25052211
PCB
P101 or SOCKET NSCT-15P1811 ( 1) 25052024
PCB
P251 PIN JACK NPJ-7PDB477 1 25045680
PCB
P253B SOCKET AS NSAS-10P0787 1 2009990578UL
PCB
P261A PLUG NPLG-3P117 1 25055133
PCB
P261B SOCKET AS NSAS-6P0675 1 2009990513UL
PCB
P301 PIN JACK NPJ-6PDRW386 1 25045571
PCB
P301 or JACK NPJ-6PDBL159 ( 1) 25045300
PCB
P301 or PIN JACK NPJ-6PDWWWRRR561 ( 1) 25045779
PCB
P304 PIN JACK NPJ-6PDRW386 1 25045571
PCB
P304 or JACK NPJ-6PDBL159 ( 1) 25045300
PCB
P304 or PIN JACK NPJ-6PDWWWRRR561 ( 1) 25045779
PCB
P305 PIN JACK NPJ-6PWRLGGP493 1 25045697
PCB
P305 or PIN JACK NPJ-6PDWLGREP562 ( 1) 25045780
PCB
P306 SOCKET AS NSAS-26P1207 1 2009990825UL
PCB
P351 PIN JACK NPJ-1PDP510 1 25045720
PCB
P351 or PIN JACK NPJ-1PDP555 ( 1) 25045773
PCB
P410B PLUG NPLG-11P663 1 25055707
