Onkyo HT-RC260 Service Manual

U007
HDM-AS(HDMI Asy)
U0070+U0071+U0072
BAHDM-0403-1E * 1 1B247503-1E N <B MDC>
U0070
HDM-AS
(
HDMI As
y)
BAHDM-0403-1E 1 1B2475403-1E N <B MDC>
U0071
PWB
(
Front HDMI As
y)
BAHDM-0404-1E 1 1B2475404-1E N <B MDC>
U0072
PWB
(
Front HDMI As
y
FIX
)
BAETC-0405-1E 1 1B2475405-1E N, NSP <B MDC>
CIRCUIT PART NAME DESCRIPTION
Q
'T
Y
PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D8161 ZENER D UDZS3.6B 1 224550360R2
D8204 DIODE DAN217T146 1 223285R2
D8204 or C-DIODE 1SS226(TE85L_F) ( 1) 223266R2 NSP
D8205 DIODE DAN217T146 1 223285R2
D8205 or C-DIODE 1SS226(TE85L_F) ( 1) 223266R2 NSP
D8301 DIODE DAN217T146 1 223285R2
D8301 or C-DIODE 1SS226(TE85L_F) ( 1) 223266R2 NSP
D8302 C-DIODE KDS4148U 1 223283R2 NSP
D8302 or C-DIODE 1SS352 ( 1) 223234R2 NSP
D8302 or C-DIODE MA2J111 ( 1) 223279R2 NSP
D8302 or C-DIODE MA2J1110GL ( 1) 223302R2 NSP
D8701 C-DIODE KDS4148U 1 223283R2 NSP
D8701 or C-DIODE 1SS352 ( 1) 223234R2 NSP
D8701 or C-DIODE MA2J111 ( 1) 223279R2 NSP
D8701 or C-DIODE MA2J1110GL ( 1) 223302R2 NSP
D8901 C-DIODE KDS4148U 1 223283R2 NSP
D8901 or C-DIODE 1SS352 ( 1) 223234R2 NSP
D8901 or C-DIODE MA2J111 ( 1) 223279R2 NSP
D8901 or C-DIODE MA2J1110GL ( 1) 223302R2 NSP
D8902 C-DIODE KDS4148U 1 223283R2 NSP
D8902 or C-DIODE 1SS352 ( 1) 223234R2 NSP
D8902 or C-DIODE MA2J111 ( 1) 223279R2 NSP
D8902 or C-DIODE MA2J1110GL ( 1) 223302R2 NSP
D8903 C-DIODE KDS4148U 1 223283R2 NSP
D8903 or C-DIODE 1SS352 ( 1) 223234R2 NSP
D8903 or C-DIODE MA2J111 ( 1) 223279R2 NSP
D8903 or C-DIODE MA2J1110GL ( 1) 223302R2 NSP
D8904 C-DIODE KDS4148U 1 223283R2 NSP
D8904 or C-DIODE 1SS352 ( 1) 223234R2 NSP
D8904 or C-DIODE MA2J111 ( 1) 223279R2 NSP
D8904 or C-DIODE MA2J1110GL ( 1) 223302R2 NSP
D8906 DIODE RB070M-30 1 22380361R2
D8906 or C-DIODE CRS09(TE85L_Q) ( 1) 223274R2 NSP
D8951 DIODE XBS303V17R 1 22380365R2 N
D8952 DIODE XBS303V17R 1 22380365R2 N
Q201 IC D788E001BRFP266Z 1 22242502R3
