Onkyo HT-RC260 Service Manual

R6135 METAL R RNU1WCJ-8.2 1 453630824T <B MDC>
R6136 METAL R RNU1WCJ-8.2 1 453630824T <B MDC>
R6600 CARBON R R16J-22 1 417342204T <B MDC>
R6601 CARBON R R16J-22 1 417342204T <B MDC>
R6602 CARBON R R16J-22 1 417342204T <B MDC>
R6603 CARBON R R16J-22 1 417342204T <B MDC>
R6604 CARBON R R16J-22 1 417342204T <B MDC>
R6605 CARBON R R16J-22 1 417342204T <B MDC>
R6606 CARBON R R16J-22 1 417342204T <B MDC>
R6610 CARBON R R16J-22 1 417342204T <B MDC>
R6611 CARBON R R16J-22 1 417342204T <B MDC>
R6612 CARBON R R16J-22 1 417342204T <B MDC>
R6613 CARBON R R16J-22 1 417342204T <B MDC>
R6614 CARBON R R16J-22 1 417342204T <B MDC>
R6615 CARBON R R16J-22 1 417342204T <B MDC>
R6616 CARBON R R16J-22 1 417342204T <B MDC>
R6690 METAL O R RS1/2WBJ-10 1 443521004T <B MDC>
R6691 METAL O R RS1/2WBJ-390 1 443523914T
R6692 METAL O R RS1/2WBJ-390 1 443523914T
[SW TRM]
JL600B SOCKET NSCT-7P99 1 25050271
JL603B SOCKET NSCT-9P101 1 25050273
JL604B SOCKET NSCT-5P97 1 25050269 <B MDC>
JL605B SOCKET NSCT-5P97 1 25050269
JL610A WIRE HOL NSCT-7P878 1 25051091
JL620B WIRE TRAP NPLG-7P590 1 25055628 <B MDC>
P6601 TRM NTM-2PDMCR400 1 25060472
P6602 TRM NTM-4PDMNRR420 1 25060492
P6603 TRM NTM-4PDMNRR420 1 25060492
P6604 TRM NTM-4PDMNRR420 1 25060492 <B MDC>
RL6600 RELAY NRL-2P5A-DC24-129 1 25065563A
RL6600 o RELAY NRL-2P5A-DC24-193 ( 1) 25065703
RL6602 RELAY NRL-2P5A-DC24-129 1 25065563A
RL6602 o RELAY NRL-2P5A-DC24-193 ( 1) 25065703
RL6603 RELAY NRL-2P5A-DC24-129 1 25065563A
RL6603 o RELAY NRL-2P5A-DC24-193 ( 1) 25065703
RL6605 RELAY NRL-2P5A-DC24-129 1 25065563A <B MDC>
RL6605 o RELAY NRL-2P5A-DC24-193 ( 1) 25065703 <B MDC>
RL6607 RELAY NRL-2P5A-DC24-129 1 25065563A <B MDC>
RL6607 o RELAY NRL-2P5A-DC24-193 ( 1) 25065703 <B MDC>
HT-RC260
PC BOARD PARTS LIS
T
