Onkyo HT-RC260

RL6901 o RELAY NRL-1P10A-DC12-198 ( 1) 25065709
RL6902 RELAY NRL-1P10A-DC12-196 1 25065707
RL6902 o RELAY NRL-1P10A-DC12-197 ( 1) 25065708
RL6902 o RELAY NRL-1P10A-DC12-198 ( 1) 25065709
HT-RC260
PC BOARD PARTS LIS
T
U002
CLA-AS(Amplifier Class_A Asy)
U0020+U0021
BACLA-0362-1A * 1 1B247562-1A N <B MDC>
U0020
CLA-AS
(
Am
p
lifier Class
_
A As
y)
BACLA-0362-1
A
1 1B2475362-1
A
N <B MDC>
U0021
PWB
(
etc reserve
)
BAETC-0363-1
A
1 1B2475363-1
A
N, NSP <B MDC>
CIRCUIT PART NAME DESCRIPTION
Q
'T
Y
PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D5000 ZENER D MTZJ5.6B 1 224470562T
D5001 ZENER D MTZJ5.6B 1 224470562T
D5002 ZENER D MTZJ5.6B 1 224470562T
D5003 ZENER D MTZJ5.6B 1 224470562T
D5004 ZENER D MTZJ5.6B 1 224470562T
D5005 ZENER D MTZJ5.6B 1 224470562T <B MDC>
D5006 ZENER D MTZJ5.6B 1 224470562T <B MDC>
Q5000 TR 2SC2240-BL(TPE2_F) 1 2211406T
Q5001 TR 2SC2240-BL(TPE2_F) 1 2211406T
Q5002 TR 2SC2240-BL(TPE2_F) 1 2211406T
Q5003 TR 2SC2240-BL(TPE2_F) 1 2211406T
Q5004 TR 2SC2240-BL(TPE2_F) 1 2211406T
Q5005 TR 2SC2240-BL(TPE2_F) 1 2211406T <B MDC>
Q5006 TR 2SC2240-BL(TPE2_F) 1 2211406T <B MDC>
Q5010 TR 2SC2240-BL(TPE2_F) 1 2211406T
Q5011 TR 2SC2240-BL(TPE2_F) 1 2211406T
Q5012 TR 2SC2240-BL(TPE2_F) 1 2211406T
Q5013 TR 2SC2240-BL(TPE2_F) 1 2211406T
Q5014 TR 2SC2240-BL(TPE2_F) 1 2211406T
Q5015 TR 2SC2240-BL(TPE2_F) 1 2211406T <B MDC>
Q5016 TR 2SC2240-BL(TPE2_F) 1 2211406T <B MDC>
Q5030 TR 2SA949-Y(TPE6_F) 1 2211354T
Q5030A RETAINER (CLA2) 1 27142140
Q5031 TR 2SA949-Y(TPE6_F) 1 2211354T
Q5031A RETAINER (CLA2) 1 27142140
Q5032 TR 2SA949-Y(TPE6_F) 1 2211354T
Q5032A RETAINER (CLA2) 1 27142140
Q5033 TR 2SA949-Y(TPE6_F) 1 2211354T
Q5033A RETAINER (CLA2) 1 27142140
