Onkyo HT-RC260

P6007A TRM NTM-1P233(M1969) 1 25060302
P6008A TRM NTM-1P233(M1969) 1 25060302
P6009A TRM NTM-1P233(M1969) 1 25060302 <B MDC>
P6010A TRM NTM-1P233(M1969) 1 25060302 <B MDC>
HT-RC260
PC BOARD PARTS LIS
T
U003
DG-AS（MPU/DAC
Asy)
U0030+U0031
BADG-0364-1Z * 1 1B247564-1Z N <B MDC>
U0030
DG-AS（MPU/DAC Asy)
BADG-0364-1Z 1 1B2475364-1Z N <B MDC>
U0031
PWB(U_port）
BAETC-0365-1Z 1 1B2475365-1Z N <B MDC>
CIRCUIT PART NAME DESCRIPTION
Q
'T
Y
PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D110 C-DIODE KDS4148U 1 223283R2 NSP
D110 or C-DIODE 1SS352 ( 1) 223234R2 NSP
D110 or C-DIODE MA2J111 ( 1) 223279R2 NSP
D111 C-DIODE KDS4148U 1 223283R2 NSP
D111 or C-DIODE 1SS352 ( 1) 223234R2 NSP
D111 or C-DIODE MA2J111 ( 1) 223279R2 NSP
D112 ZENER D UDZS10B 1 224551000R2 <B MDC>
D131 C-DIODE KDS4148U 1 223283R2 NSP
D131 or C-DIODE 1SS352 ( 1) 223234R2 NSP
D131 or C-DIODE MA2J111 ( 1) 223279R2 NSP
D132 C-DIODE KDS4148U 1 223283R2 NSP
D132 or C-DIODE 1SS352 ( 1) 223234R2 NSP
D132 or C-DIODE MA2J111 ( 1) 223279R2 NSP
D182 DIODE RL1N4003 1 22380260T
D183 DIODE RL1N4003 1 22380260T
D601 C-DIODE KDS4148U 1 223283R2 NSP
D601 or C-DIODE 1SS352 ( 1) 223234R2 NSP
D601 or C-DIODE MA2J111 ( 1) 223279R2 NSP
D701 C-DIODE KDS4148U 1 223283R2 NSP
D701 or C-DIODE 1SS352 ( 1) 223234R2 NSP
D701 or C-DIODE MA2J111 ( 1) 223279R2 NSP
D702 C-DIODE KDS4148U 1 223283R2 NSP
D702 or C-DIODE 1SS352 ( 1) 223234R2 NSP
D702 or C-DIODE MA2J111 ( 1) 223279R2 NSP
Q111 TR 2SC2235-Y(TPE6_F) 1 2211654T <B MDC>
Q131 IC TC74HCU04AF 1 222740046R2TO
Q131 or IC 74HCU04F ( 1) 222740046R2
Q153 IC R1EX25064ASA00A 1 22242581R2
