Onkyo HT-RC260 Service Manual

P7402 ST JACK MSJ-035-05C B AG SR type 1 25045879 <B MDC>
P901A PLUG NPLG-2P631 1 25055675
P901Aor PLUG 1-1123724-2 ( 1) 25056402
P911 PLUG NPLG-2P631 1 25055675
P911 or PLUG 1-1123724-2 ( 1) 25056402
RL901 RELAY NRL-1P10A-DC9-186 1 25065683 <B MDC>
S7002 R ENCODE EC12E2425WITH WASHER 1 25065655W
S7102 PUSH SW NPS-111-S681 1 25035718T
S7106 PUSH SW NPS-111-S681 1 25035718T
S7108 PUSH SW NPS-111-S681 1 25035718T
S7116 PUSH SW NPS-111-S681 1 25035718T <B MDC>
S7118 PUSH SW NPS-111-S681 1 25035718T <B MDC>
S7120 PUSH SW NPS-111-S681 1 25035718T <B MDC>
S7122 PUSH SW NPS-111-S681 1 25035718T <B MDC>
S7124 PUSH SW NPS-111-S681 1 25035718T <B MDC>
S7126 PUSH SW NPS-111-S681 1 25035718T <B MDC>
S7128 PUSH SW NPS-111-S681 1 25035718T <B MDC>
S7130 PUSH SW NPS-111-S681 1 25035718T <B MDC>
S7132 PUSH SW NPS-111-S681 1 25035718T
S7134 PUSH SW NPS-111-S681 1 25035718T
S7136 PUSH SW NPS-111-S681 1 25035718T
S7138 PUSH SW NPS-111-S681 1 25035718T
S7140 PUSH SW NPS-111-S681 1 25035718T
S7142 PUSH SW NPS-111-S681 1 25035718T
S7144 PUSH SW NPS-111-S681 1 25035718T
S7146 PUSH SW NPS-111-S681 1 25035718T
S7148 PUSH SW NPS-111-S681 1 25035718T
S7150 PUSH SW NPS-111-S681 1 25035718T
S7152 PUSH SW NPS-111-S681 1 25035718T
S7154 PUSH SW NPS-111-S681 1 25035718T
S7156 PUSH SW NPS-111-S681 1 25035718T
S7158 PUSH SW NPS-111-S681 1 25035718T
S7160 PUSH SW NPS-111-S681 1 25035718T
S7162 PUSH SW NPS-111-S681 1 25035718T
S7164 PUSH SW NPS-111-S681 1 25035718T
[TUNER UNIT]
U7041 REMO SENS KSM-603TE5B 1 24130019
HT-RC260
PC BOARD PARTS LIS
T
U006
TRM-AS(SP Terminal Asy)
U0060+U0061+U0062+U0063
BATRM-0368-1J * 1 1B247568-1J N <B MDC>
U0060
TRM-AS
(
SP Terminal As
y)
BATRM-0368-1J 1 1B2475368-1J N <B MDC>
