CONFIRMATION OF FL TUBE AND LED
1. Do the following operation.
2. Confirm that all LEDs and all segments of FL tube are lit.
[TV/CD] + [ON/STANDBY] → [DIMMER]
CONFIRMATION OF HEAD PHONE OPERATION
Confirm the Listening Mode is automatically switched to "STEREO" mode when headphones plug is inserted
into the PHONES jack.
Instead of the confirmation of "STEREO" mode, confirm light on headphone indicatior in FL when headphones plug is inserted.
CONFIRMATION OF FM RADIO OPERATION
1. Setting of Signal Generator(SG)
Carrier frequency any
Modulation 1kHz
Deviation 75kHz
Output level 35dBu
2. Waveform confirmation
Set the signal of SG as following channels and confirm output is the following table.
SG Input
Lch R ch
(1) R ch only No Yes
(2) L + R ch Yes Yes
3. Confirmation of Stereo indicator
Set SG as stereo and confirm stereo indicator is on.
4. Confirmation of Auto stop operation
Do auto tuning (Press TUNING UP or TUNING DOWN button) and confirm that the searching stops when a station that
is set by SG is found.
Output
CONFIRMATION OF RDS (RADIO DATA SYSTEM) OPERATION (Applied to MPP/MPB/MM* type )
1. Input 98MHz,30dBμ signal modulated with RDS data.
2. When a PS information is received, the name of the station "RDS TEST" shall be displayed within 2 seconds
instead of the frequency.
CONFIRMATION OF OSD(ON SCREEN DISPLAY) OPERATION
1. When HOME button is pushed, confirm that setup menu is displayed in HDMI Out.
2. Confirm that specified operations for ENTER(with 4-cursor) buttons are made.
CONFIRMATION OF CEC OPERATION
1. Connect AVR's HDMI OUT to HDMI input of appliance compatible with CEC(SINK or REPEATER) by HDMI cable.
2. Turn on the power to the AVR
FL tube will display "OK" or "NG".
to the following test mode.
TEST 6-00
3-2. [TV/CD] + [ON/STANDBY] → [AUX]
3-1. set the volume level to 25.
3. Do the following operation.
CONFIRMATION OF VIDEO SIGNAL-DETECTION
2. Confirm the following indicator lights up on the FL TUBE when the following video signal is input.
3. Furthermore, confirm the following indicator is turned off on the FL TUBE when the following video signal isn't input at the
following test mode as well.
Input terminal
Indicator
(1) (2)
Composite
FM STEREO
Component
RDS
1-2. [TV/CD] + [ON/STANDBY] → [PC]
1-1. set the volume level to 25.
1. Do the following operation.
to the following test mode.
TEST 5-01
1-3. [TONE +]
Confirm Video output signal as shown Table-2, while Video signal are input as shown Table-1 in "Video in_out" sheet.
Table-1
Table-2
<NOTE>Confirm the HDMI path at 1080p signal.
CONFIRMATION OF VIDEO IN/OUT
CONFIRMATION OF FL DISPLAY
The contents of the step are as follows.
1. Lit all segment
2. Lit '23456789ABCDEF'.
3. Lit a even number segment
4. Lit an odd number segment
5. The Destination setting is displayed.
1-2. [TV/CD] + [ON/STANDBY] → [DIMMER(RT/PTY/TP)]
1-1. set the volume level to 25.
1. Do the following operation.
to the FL test mode
[TONE-] = Step down
[TONE+] = Step up
All SP-RELAYs are turned ON only at the time of this STEP.
Moreover, whether make RELAY restoration time at the time of protection operation into 1 second, and PROTECT input "H" is detected
how many times or it continues 1 second or more, RELAY is not held at OFF or POWER OFF is not carried out, either.
When "H" is 1 seconds or more to PROTECT input and it is set to "L", RELAY is turned ON again.
Moreover, not any MUTE is outputted at the time of this STEP.
*1
If voltage-detection protector check in TEST-1-01 starts, DC voltage is output immediately from each channel. (within 100msec.)
*3
The following signal is output from all channel continuously in TEST1-09.
2mS
20mS
2mS
MAX
-
MAX
*4
1. Press TEST TONE on remote controller then press CH SELECT repeatedly.
Set turn to Dolby Test mode tone Check speaker condition.
2. Please check that a sound comes out from each channel.
-> FL ch -> C ch -> FR ch -> SR ch -> SL ch -> SW ch ->
CONFIRMATION OF DOLBY TEST TONE
Auto Measurement Mode
Component HDMI
BD/DVD --- --- --- IN1 G
CBL/SAT A IN1 E IN2 H
STB/DVR B --- --- IN3 I
GAME C --- --- IN4 J
--- --- --- --- IN5 K
--- --- --- --- IN6 L
AUX D --- --- --- ---
Output
Test mode
5-00(BD/DVD)
5-01(CBL/SAT)
5-02(STB/DVR)
5-03(GAME)
5-04(PC)
5-05(IN6)
5-07(AUX)
Analog Input Only
TEST DSP DSP DSP Config. Master Speaker 12V etc.
No Output Output Output SW/F/C/S Vol. Relay TRG
ch Frequency Voltage
1-00 SELECTOR MUTING TIME REDUCTION MODE - - - Y/L/L/L 64(Ref) F -
1-01 IDLING TIMER Timer start - - - Y/L/L/L Min(Min) F - IDLING TIMER
V Protect (FL) FL +DC +Max Y/L/L/L Max(Max) F/CS - *1, *3 +DC Protect
V Protect (FR) FR -DC -Max Y/L/L/L Max(Max) F/CS - *1, *3 -DC Protect
V Protect (C) C +DC +Max Y/L/L/L Max(Max) F/CS - *1, *3 +DC Protect
V Protect (SL) SL -DC -Max Y/L/L/L Max(Max) F/CS - *1, *3 -DC Protect
V Protect (SR) SR +DC +Max Y/L/L/L Max(Max) F/CS - *1, *3 +DC Protect
V Protect (SW) SW -DC -Max Y/L/L/L Max(Max) F/CS - *1, *3 -DC Protect
UPDATE ROUTE - - - Y/L/L/L Min(Min) F -
UPDATE ROUT CHECK
Wi-Fi check - - - Y/L/L/L Min(Min) F - Wi-Fi check
USB Confirmation - - - Y/L/L/L Min(Min) F -
1-02 MULTI TONE 1kHz + 30Hz + 20kHz , -20dBFS ALL
1kHz+30Hz+20kHz
-20dBFS Y/L/L/L 64(Ref) F/CS - *6 Multi tone
1-03 Wi-Fi check - - - Y/L/L/L Min(Min) F - Wi-Fi check
1-04 UPDATE ROUTE - - - Y/L/L/L Min(Min) - -
UPDATE ROUT CHECK
1-05 DISPLAY IP ADDRESS - - - Y/L/L/L Min(Min) - - IP ADDRESS
1-06 KEY TEST - - - Y/L/L/L 76(-6dB) F/C - *7 KEY TEST
1-07 VOLH DET / FAN HIGH-SPEED / 12V TRIGGER C
C,SL,SR
1kHz 0dBFS Y/L/L/L 64(Ref) F/CS C *5 VOLH DET,FAN High
1-08 VOLH DET / FAN LOW-SPEED / 12V TRIGGER B (ZONE3)
FL,FR,C,SL,SR,SW
1kHz 0dBFS Y/L/L/L 64(Ref) F/CS B (Z3) *5 VOLH DET,FAN Low
1-09 CURRENT PROTECT / 12V TRIGGER A (ZONE2) ALL Pulse Max Y/L/L/L 58(76) F/CS A (Z2)
*1, *4 Current Protect
Analog Input Listening Mode/ VIDEO Compo- HDMI 12V Digital Input Config. Master Vol. Speaker etc.
No [Rec Sel] Input Format Input nent V TRG
/Output NonTHX Relay
(Zone2/Zone3) (THX)
2-00
Fch -> BD/DVD
Cch -> STB/DVR
Sch -> CBL/SAT
SWch -> STB/DVR
Z2/Z3 -> (Off)
Stereo(Direct) BD/DVD IN1 - - - - Max(Max) F/CS
T4,H64,
T5,
T6,H66,D3
LINE GAIN,HUM NOISE
BD/DVD (Off) Whole House Mode BD/DVD IN1 - - - - Max(Max) F/CS Except the above models.
2-01 BD/DVD (Off) ADC DSP 8ch Thru. BD/DVD IN1 - - - Y/L/L/L 57(Max) F/CS
ADC GAIN etc.
2-02 BD/DVD (Off) ADC DSP 8ch Thru. BD/DVD IN1 - - - Y/L/L/L MIN(Min) F/CS
MIN NOISE
2-03 CBL/SAT (Off) DIR DSP 8ch Thru CBL/SAT - - - *OPT1 Y/L/L/L Max(Max) F/CS AMUT OFF
DAC HUM NOISE
2-04 MIC ADC DSP 8ch Thru. BD/DVD BD/DVD - - - Y/L/L/L Max(Max) F/CS
MIC GAIN
2-05 MIC ADC DSP 8ch Thru. BD/DVD BD/DVD - - - Y/L/L/L Max(Max) F/CS
MICMUTE ON
MIC MUTING
2-06 PHONO/Source Direct BD/DVD - - - - - Max(Max) F
PHONO GAIN etc.
2-07 BD/Source Bi AMP BD/DVD IN1 - - - - Max (+18dB) F/C/S
Bi AMP
2-08 BD/DVD (Off) ADC DSP 8ch Thru. BD/DVD IN1 - - - Y/L/L/L Max (+18dB) F/CS
ADC GAIN etc.
2-09 BD(BALANCE
)
ADC DSP 8ch Thru. BD/DVD IN1 - - - Y/L/L/L Max (+18dB) F/CS
BALANCE
2-10 BD(BALANCE
)
ADC DSP 8ch Thru. BD/DVD IN1 - - - Y/L/L/L Max (+18dB) F/CS
BALANCE:MONO
2-11 BD/DVD (Off) ADC DSP 8ch Thru. BD/DVD IN1 - - - Y/L/L/L Max(Max) CS SPRLF OFF
PREOUT RELAY OFF
2-12 BD/DVD (Off) Stereo(Direct) BD/DVD IN1 - - - - Max(Max) F SW=NO
HP GAIN/SP-B GAIN
3-00 FM/Source Stereo(Direct) BD/DVD BD/DVD - - - - 64(Ref) F
Z2 LINEOUT
3-01 GAME(BD/TV) Stereo(Direct) BD/DVD BD/DVD - - - - Max(Max) F/Z2
Powered:ON
,
TX:LINE/DTR:PRE
,
Z2VOL: 64(82)
3-02 GAME(BD/TV) Stereo(Direct) BD/DVD BD/DVD - - - - Max(Max) F/Z2
Z2MUTE ON
Powered:ON
,
LINE/PRE:LINE
,
Z2VOL:64(82)
3-03 GAME(BD/TV) Stereo(Direct) BD/DVD BD/DVD - - - - Max(Max) F/Z2
Powered:ON
LINE/PRE:PRE
Z2/Z3Vol=64(82)
Z2 Bass=Max
3-04 GAME(BD/TV) Stereo(Direct) BD/DVD BD/DVD - - - - Max(Max) F/Z2
Powered:ON
LINE/PRE:PRE
Z2/Z3Vol=64(82)
Z2 Bass=Min
3-05 GAME(BD/TV) Stereo(Direct) BD/DVD BD/DVD - - - - Max(Max) F/Z2
Powered:ON
LINE/PRE:PRE
Z2/Z3Vol=64(82)
Z2 Treble=Max
3-06 GAME(BD/TV) Stereo(Direct) BD/DVD BD/DVD - - - - Max(Max) F/Z2
Powered:ON
LINE/PRE:PRE
Z2/Z3Vol=64(82)
Z2 Treble=Min
3-07 GAME(BD/TV) Stereo(Direct) BD/DVD - - - - - Max(Max) F/Z2
Z2/Z3PRE VOL MAX ATT
3-08 GAME(BD/TV) Stereo(Direct) BD/DVD - - - - - MIN(Min) F/Z2 Z2/Z3 LINEOUT (Mid)
3-09 USB Stereo(Direct) Last - - - Rear USB - MIN(Min)
F
- -
TEST DSP Output channel DSP DSP Config. Master Speaker etc.
No. Output Output Vol. Relay
Frequency Voltage
4-00 ALL
1kHz (SW:30Hz)
-20dBFS Y/L/L/L 64(Ref) F/CS *6
4-01 ALL
30Hz (SW
:
1kHz)
-20dBFS Y/L/L/L 64(Ref) F/CS *6
4-02 ALL 20kHz -20dBFS Y/L/L/L 64(Ref) F/CS *6 DSP Freq.Response
4-03 SW 30Hz -20dBFS N/L/L/L 58(76) F/CS *6 Characteristic(1)
4-04 FL,FR 30Hz -20dBFS N/L/L/L 64(Ref) F/CS *6 Characteristic(2)
4-05 ALL
1kHz (SW
:
30Hz)
-20dBFS Y/L/L/L 64(Ref) F/CS Mute On *6 Muting
4-06 ALL
1kHz (SW
:
30Hz)
-20dBFS Y/L/L/L Min(Min) F/CS *6 Volume Max.Attenuation
4-07 FR,C,SL,SR,SW 10kHz -20dBFS Y/L/L/L 64(Ref) F/CS Mute:FL *6 Separation(FL)
4-08 FL,C,SL,SR,SW 10kHz -20dBFS Y/L/L/L 64(Ref) F/CS Mute:FR *6 Separation(FR)
4-09 FL,FR,SL,SR,SW 10kHz -20dBFS Y/L/L/L 64(Ref) F/CS Mute:C *6 Separation(C)
4-10 FL,FR,C,SR,SW 10kHz -20dBFS Y/L/L/L 64(Ref) F/CS Mute:SL *6 Separation(SL)
4-11 FL,FR,C,SL,SW 10kHz -20dBFS Y/L/L/L 64(Ref) F/CS Mute:SR *6 Separation(SR)
4-12
FL,FR,C,SL,SR,SBR,SW 10kHz -20dBFS Y/L/L/L/L 64(Ref) F/CS/SB Mute:SBL *6 Separation(SBL)
4-13 FL,FR,C,SL,SR,SBL,SW 10kHz -20dBFS Y/L/L/L/L 64(Ref) F/CS/SB Mute:SBR *6 Separation(SBR)
4-14 FL,FR,C,SL,SR 30Hz -20dBFS Y/L/L/L 64(Ref) F/CS Mute:SW *6 Separation(SW)
4-15
F,C,SUR,SBR,HR,Wide,SW 10kHz -20dBFS Y/L/L/L/L 82 (0dB)
F/C/S/SB/H/W
Mute:LH *6 Separation(FHL)
4-16 F,C,SUR,SBR,HL,Wide,SW 10kHz -20dBFS Y/L/L/L/L 82 (0dB)
F/C/S/SB/H/W
Mute:RH *6 Separation(FHR)
4-17 F,C,SUR,SRB,High,RW,SW 10kHz -20dBFS Y/L/L/L/L 82 (0dB)
F/C/S/SB/H/W
Mute:LW *6 Separation(FWL)
4-18 F,C,SUR,SRB,High,LW,SW 10kHz -20dBFS Y/L/L/L/L 82 (0dB)
F/C/S/SB/H/W
Mute:RW *6 Separation(FWR)
4-19 FL +DC +Max Y/L/L/L Max(Max) F/CS *1,*3 +DC Protect(FL)
4-20 FR -DC -Max Y/L/L/L Max(Max) F/CS *1,*3 -DC Protect(FR)
4-21 C +DC +Max Y/L/L/L Max(Max) F/CS *1,*3 +DC Protect(C)
4-22 SL -DC -Max Y/L/L/L Max(Max) F/CS *1,*3 -DC Protect(SL)
4-23 SR +DC +Max Y/L/L/L Max(Max) F/CS *1,*3 +DC Protect(SR)
4-24 SW -DC -Max Y/L/L/L Max(Max) F/CS *1,*3 -DC Protect(SW)
DSP Gain
DSP Freq.Response
VOLH is detected and H/L of SEC1H is changed.
A detection level is the same as the normal mode.
When it is detected, light "FM STEREO" on FL TUBE.
*5.
*6 PRRLF=ON
In TEST 1-06, some character is displayed while pushing down some button. Another character shall be displayed by each button. *7
[NOTES]
1: DSP Thru of Listening Mode outputs L Input signal to L/C/SL, and outputs R Input signal to R/SR/SW.
2: Config. is in order of SW/Front/Center/Surround.
3: Mute is function to stop output(from the channel) by using inner DSP programming.
4: When Listening Mode is DSP thru, an analog SW is changed into the state of SURROUND.
5: At the time of PRTCTTHM detection, it is displayed on FLT as "THERMAL PROTECT".
6: In all test modes, it is not concerned with detection of VOLH but SEC1H are made "H" fixation. (Except TEST 1-07 and 1-08.)
7: TEST of NET/USB can't do immediately after the start-up.
It should be measure after other TEST.
8: After initialization of Net or USB, start TEST 1-04.
TX-SR333/ HT-R393/ HT-RC630
TX-SR333/ HT-R393/ HT-RC630 TX-SR333/ HT-R393/ HT-RC630
TX-SR333/ HT-R393/ HT-RC630
OPERATION CHECK-5 OPERATION CHECK-6
OPERATION CHECK-7
OPERATION CHECK-8
