Onkyo HT-RC630 User Manual

8/38 PAGE
1
R4056 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 1 435032244R1
1
R4057 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 1 435032244R1
1
R4058 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 1 435032244R1
1
R4059 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 1 435032244R1
1
R4060 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 1 435032244R1
1
R4077 CHIP TYPE CARBON RESISTOR RN72K1J-223JE 1 435032234R1
1
R4078 CHIP TYPE CARBON RESISTOR RN72K1J-473JE 1 435034734R1
1
R4079 CHIP TYPE CARBON RESISTOR RN72K1J-473JE 1 435034734R1
1
R4082 CHIP TYPE CARBON RESISTOR RN72K1J-104JE 1 435031044R1
1
R4087 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 1 435031034R1
1
R4088 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 1 435031034R1
1
R4090 CHIP TYPE CARBON RESISTOR RN72K1J-123JE 1 435031234R1
1
R4091 CHIP TYPE CARBON RESISTOR RN72K1J-223JE 1 435032234R1
1
R4092 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 1 435033314R1
1
R4093 CHIP TYPE CARBON RESISTOR RN72K1J-332JE 1 435033324R1
1
R4094 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 1 435031034R1
1
R4095 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 1 435031034R1
1
R4096 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 1 435033314R1
1
R4097 CHIP TYPE CARBON RESISTOR RN72K1J-332JE 1 435033324R1
1
R4098 CHIP TYPE CARBON RESISTOR RN72K1J-123JE 1 435031234R1
1
R4099 CHIP TYPE CARBON RESISTOR RN72K1J-223JE 1 435032234R1
1
R4100 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 1 435032244R1
1
R4101 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 1 435032244R1
1
R4102 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 1 435032244R1
1
R4103 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 1 435032244R1
1
R4104 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 1 435032244R1
1
R4107 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 1 435032244R1
1
R4110 CHIP TYPE CARBON RESISTOR RN72K1J-222JE 1 435032224R1
1
R4111 CHIP TYPE CARBON RESISTOR RN72K1J-222JE 1 435032224R1
1
R4112 CHIP TYPE CARBON RESISTOR RN72K1J-222JE 1 435032224R1
1
R4113 CHIP TYPE CARBON RESISTOR RN72K1J-222JE 1 435032224R1
1
R4114 CHIP TYPE CARBON RESISTOR RN72K1J-222JE 1 435032224R1
1
R4117 CHIP TYPE CARBON RESISTOR RN72K1J-271JE 1 435032714R1
1
R4121 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 1 435031034R1
1
R4122 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 1 435031034R1
1
R4123 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 1 435031034R1
1
R4124 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 1 435031034R1
1
R4127 CHIP TYPE CARBON RESISTOR RN72K1J-101JE 1 435031014R1
1
R4130 CHIP TYPE CARBON RESISTOR RN72K1J-221JE 1 435032214R1
1
R4131 CHIP TYPE CARBON RESISTOR RN72K1J-473JE 1 435034734R1
1
R4132 CHIP TYPE CARBON RESISTOR RN72K1J-153JE 1 435031534R1
1
R4133 CHIP TYPE CARBON RESISTOR RN72K1J-122JE 1 435031224R1
1
R4134 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 1 435031034R1
1
R4160 METAL RESISTOR RNU1WCJ-0.22 1 453632294T
1
R4161 METAL RESISTOR RNU1WCJ-0.22 1 453632294T
1
R4166 CHIP TYPE CARBON RESISTOR RN72K1J-220JE 1 435032204R1
1
R4167 CHIP TYPE CARBON RESISTOR RN72K1J-220JE 1 435032204R1
1
R4174 METAL OXIDE FILM RESISTOR RS1WBJ-68 1 443626804T
1
R4175 METAL OXIDE FILM RESISTOR RS1WBJ-68 1 443626804T
1
R4176 METAL OXIDE FILM RESISTOR RS1WBJ-47 1 443624704T
1
R4177 METAL OXIDE FILM RESISTOR RS1WBJ-47 1 443624704T
1
R4181 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 1 435032244R1
1
R4182 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 1 435032244R1
1
R4185 METAL RESISTOR RNU1WCJ-4.7 1 453630474T
1
R4187 METAL OXIDE FILM RESISTOR RS1WBJ-10 1 443621004T
1
R4189 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 1 435032244R1
1
R4190 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 1 435032244R1
1
R4211 CHIP TYPE CARBON RESISTOR RN72K1J-102JE 1 435031024R1
1
R4292 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 1 435032244R1
1
R4293 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 1 435032244R1
1
R4294 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 1 435032244R1
1
R4304 CHIP TYPE CARBON RESISTOR RN72K1J-101JE 1 435031014R1

Onkyo HT-RC630 Specifications

General

Output level	100 mV
Receiver type	Surround
Frequency range	5 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Dynamic power per channel (3 Ohm)	160 W
Dynamic power per channel (4 Ohm)	125 W
Dynamic power per channel (8 Ohm)	85 W
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	6
Audio (L/R) in	7
Composite video in	4
Digital audio coaxial in	2
Component video (YPbPr/YCbCr) in	1
Speakers connectivity type	-
Bluetooth	Yes
Ethernet LAN	No
Bluetooth version	2.1+EDR
Bluetooth profiles	A2DP, AVRCP
AM band range	522 - 1710 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Product color	Black
Audio decoders	Dolby TrueHD, DTS-HD Master Audio
Damping factor	60
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W
Package weight	10500 g

Weight and Dimensions

Depth	321 mm
Width	435 mm
Height	150 mm
Weight	8100 g
