Onkyo HT-RC630 User Manual

7/38 PAGE
1
C6051 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-103J 1 374721034T
1
C6052 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-103J 1 374721034T
1
C6053 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-103J 1 374721034T
1
C6054 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-103J 1 374721034T
1
C6250 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-473J 1 374724734T
1
C6251 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-473J 1 374724734T
1
C6252 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-473J 1 374724734T
1
C6253 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-473J 1 374724734T
1
C6254 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-473J 1 374724734T
1
C6301 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
C6401 ELECTROLYTIC CAPACITOR CE69W63V-6800M 1 3504506
C6402 ELECTROLYTIC CAPACITOR CE69W63V-6800M 1 3504506
1
C6403 TF TYPE PLASTIC FILM CAPACITOR ECQ-V100V-334J 1 374733344T
1
C6404 TF TYPE PLASTIC FILM CAPACITOR ECQ-V100V-334J 1 374733344T
1
C6411 CHIP TYPE CERAMIC CAPACITOR CK725B1H-104K1 1 332101045R1
C6451 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W25V-220M(UTSP) 1 397552217T
1
C6452 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
C6453 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V-1M(UTSP) 1 397580107AT
C6454 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V-1M(UTSP) 1 397580107AT
1
C6455 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
C6456 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V-10M(UTSP) 1 397581007AT
1
C6600 CHIP TYPE CERAMIC CAPACITOR CK725F1H-104Z1 1 332151040R1
1
C6601 CHIP TYPE CERAMIC CAPACITOR CK725F1H-104Z1 1 332151040R1
1
C6602 CHIP TYPE CERAMIC CAPACITOR CK725F1H-104Z1 1 332151040R1
1
C6650 MKT TYPE CAPACITOR B32529C0102J289 1 376491024T
1
C6651 MKT TYPE CAPACITOR B32529C0102J289 1 376491024T
1
C6652 MKT TYPE CAPACITOR B32529C0102J289 1 376491024T
1
C6653 MKT TYPE CAPACITOR B32529C0102J289 1 376491024T
1
C6654 MKT TYPE CAPACITOR B32529C0102J289 1 376491024T
[RESISTOR]
1
R1000 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 1 435033314R1
1
R1001 CHIP TYPE CARBON RESISTOR RN72K1J-750JE 1 435037504R1
1
R1002 CHIP TYPE CARBON RESISTOR RN72K1J-750JE 1 435037504R1
1
R1003 CHIP TYPE CARBON RESISTOR RN72K1J-100JE 1 435031004R1
1
R1004 CHIP TYPE CARBON RESISTOR RN72K1J-100JE 1 435031004R1
1
R1005 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 1 435032244R1
1
R1006 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 1 435032244R1
1
R1007 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 1 435031034R1
1
R1008 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 1 435031034R1
1
R1009 CHIP TYPE CARBON RESISTOR RN72K1J-823JE 1 435038234R1
1
R1010 CHIP TYPE CARBON RESISTOR RN72K1J-823JE 1 435038234R1
1
R1011 CHIP TYPE CARBON RESISTOR RN72K1J-101JE 1 435031014R1
1
R4003 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 1 435033314R1
1
R4004 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 1 435033314R1
1
R4009 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 1 435033314R1
1
R4010 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 1 435033314R1
1
R4013 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 1 435033314R1
1
R4014 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 1 435033314R1
1
R4015 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 1 435033314R1
1
R4016 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 1 435033314R1
1
R4017 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 1 435033314R1
1
R4018 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 1 435033314R1
1
R4019 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 1 435033314R1
1
R4020 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 1 435033314R1
1
R4027 CHIP TYPE CARBON RESISTOR RN72K1J-101JE 1 435031014R1
1
R4043 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 1 435032244R1
1
R4044 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 1 435032244R1
1
R4049 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 1 435032244R1
1
R4050 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 1 435032244R1
1
R4053 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 1 435032244R1
1
R4054 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 1 435032244R1
1
R4055 CHIP TYPE CARBON RESISTOR RN72K1J-224JE 1 435032244R1

Onkyo HT-RC630 Specifications

General

Output level	100 mV
Receiver type	Surround
Frequency range	5 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Dynamic power per channel (3 Ohm)	160 W
Dynamic power per channel (4 Ohm)	125 W
Dynamic power per channel (8 Ohm)	85 W
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	6
Audio (L/R) in	7
Composite video in	4
Digital audio coaxial in	2
Component video (YPbPr/YCbCr) in	1
Speakers connectivity type	-
Bluetooth	Yes
Ethernet LAN	No
Bluetooth version	2.1+EDR
Bluetooth profiles	A2DP, AVRCP
AM band range	522 - 1710 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Product color	Black
Audio decoders	Dolby TrueHD, DTS-HD Master Audio
Damping factor	60
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W
Package weight	10500 g

Weight and Dimensions

Depth	321 mm
Width	435 mm
Height	150 mm
Weight	8100 g
