Onkyo HT-RC630 User Manual

6/38 PAGE
1
C4014 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-221J1 1 342102214R1
1
C4015 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-221J1 1 342102214R1
1
C4016 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-221J1 1 342102214R1
1
C4017 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-221J1 1 342102214R1
1
C4018 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-221J1 1 342102214R1
1
C4019 UPZ TYPE PLASTIC FILM CAPACITOR 2AUPZTF221JE 1 376332214T
1
C4020 UPZ TYPE PLASTIC FILM CAPACITOR 2AUPZTF221JE 1 376332214T
1
C4027 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-221J1 1 342102214R1
C4050 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W25V-220M(UTSP) 1 397552217T
C4051 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W25V-220M(UTSP) 1 397552217T
C4052 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W25V-220M(UTSP) 1 397552217T
C4053 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W25V-220M(UTSP) 1 397552217T
C4054 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W25V-220M(UTSP) 1 397552217T
C4055 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W25V-220M(UTSP) 1 397552217T
C4056 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W25V-220M(UTSP) 1 397552217T
C4057 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W25V-220M(UTSP) 1 397552217T
C4060 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W25V-47M(UTSP) 1 397554707AT
C4061 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W25V-47M(UTSP) 1 397554707AT
C4070 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 1 397584707AT
C4071 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 1 397584707AT
C4072 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 1 397584707AT
C4073 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 1 397584707AT
C4074 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 1 397584707AT
C4077 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 1 397584707AT
1
C4090 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-101J1 1 342101014R1
1
C4091 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-101J1 1 342101014R1
1
C4095 CHIP TYPE CERAMIC CAPACITOR CK725B1H-103K1 1 332101035R1
C4100 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 1 397584707AT
C4101 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 1 397584707AT
C4102 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 1 397584707AT
C4103 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 1 397584707AT
C4104 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 1 397584707AT
C4107 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V-10M(UTSP) 1 397581007AT
C4108 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 1 397584707AT
C4109 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 1 397584707AT
C4130 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 1 397584707AT
1
C4131 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-221J1 1 342102214R1
1
C4132 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-103J 1 374721034T
C4166 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W25V-220M(UTSP) 1 397552217T
C4167 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W25V-220M(UTSP) 1 397552217T
1
C4170 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-104J 1 374721044T
1
C4171 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-104J 1 374721044T
C4172 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 1 397584707AT
C4173 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 1 397584707AT
C4174 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W16V-470M(UTSP) 1 397544717T
C4175 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W16V-470M(UTSP) 1 397544717T
C4209 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W25V-47M(UTSP) 1 397554707AT
C4210 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W25V-47M(UTSP) 1 397554707AT
1
C4212 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-104J 1 374721044T
1
C4219 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-102J1 1 342101024R1
1
C4300 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-334J 1 374723344T
C4301 JAMICON TYPE ELECTROLYTIC CAPACITOR CE04W35V-1000M 1 398561027T
C4301 or VR TYPE ELECTROLYTIC CAPACITOR CE04W35V-1000M(VR) ( 1) 394661027T
C4302 JAMICON TYPE ELECTROLYTIC CAPACITOR CE04W35V-1000M 1 398561027T
C4302 or VR TYPE ELECTROLYTIC CAPACITOR CE04W35V-1000M(VR) ( 1) 394661027T
1
C4303 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-334J 1 374723344T
1
C4305 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-221J1 1 342102214R1
1
C4306 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-221J1 1 342102214R1
1
C4324 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-102J1 1 342101024R1
1
C4400 CHIP TYPE CERAMIC CAPACITOR CK725B1H-102K1 1 332101025R1
1
C4401 CHIP TYPE CERAMIC CAPACITOR CK725B1H-102K1 1 332101025R1
1
C6050 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-103J 1 374721034T

Onkyo HT-RC630 Specifications

General

Output level	100 mV
Receiver type	Surround
Frequency range	5 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Dynamic power per channel (3 Ohm)	160 W
Dynamic power per channel (4 Ohm)	125 W
Dynamic power per channel (8 Ohm)	85 W
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	6
Audio (L/R) in	7
Composite video in	4
Digital audio coaxial in	2
Component video (YPbPr/YCbCr) in	1
Speakers connectivity type	-
Bluetooth	Yes
Ethernet LAN	No
Bluetooth version	2.1+EDR
Bluetooth profiles	A2DP, AVRCP
AM band range	522 - 1710 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Product color	Black
Audio decoders	Dolby TrueHD, DTS-HD Master Audio
Damping factor	60
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W
Package weight	10500 g

Weight and Dimensions

Depth	321 mm
Width	435 mm
Height	150 mm
Weight	8100 g
