1
Q4117 or TRANSISTOR RN1441 ( 1) 2215410R2
1
Q4130 HYBRID IC NJM4580M-D 1 22241448R2
Q4170 HYBRID IC 78M15HF(NJM78M15FA) 1 222780155JRC
1
Q4170A HEAT SINK ME151025402170 1 27160692
1
Q4170B SCREW 3P+10FN(3BC) 1 82143010GR
Q4171 HYBRID IC 79M15HF(NJM79M15FA) 1 222790155JRC
1
Q4171A HEAT SINK ME151025402170 1 27160692
1
Q4171B SCREW 3P+10FN(3BC) 1 82143010GR
1
Q4302 TRANSISTOR RTAN430C-T112-1 1 2217780R2
1
Q4302 or TRANSISTOR RN1441 ( 1) 2215410R2
1
Q4303 TRANSISTOR RTAN430C-T112-1 1 2217780R2
1
Q4303 or TRANSISTOR RN1441 ( 1) 2215410R2
1
Q6000 TRANSISTOR KTC3875-GR 1 2216175R2
1
Q6000 or TRANSISTOR 2SC2412K-R ( 1) 2214653R2
1
Q6001 TRANSISTOR KTC3875-GR 1 2216175R2
1
Q6001 or TRANSISTOR 2SC2412K-R ( 1) 2214653R2
1
Q6002 TRANSISTOR KTC3875-GR 1 2216175R2
1
Q6002 or TRANSISTOR 2SC2412K-R ( 1) 2214653R2
1
Q6003 TRANSISTOR 2SD2704K 1 2218130R2
1
Q6004 TRANSISTOR 2SD2704K 1 2218130R2
1
Q6070 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q6071 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q6072 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q6073 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q6074 TRANSISTOR 2SC2713-BL 1 2213136R2
Q6300 HYBRID IC LM61CIZ 1 22242212
1
Q6300A RETAINER (PTH) 1 27141884-1
1
Q6401 TRANSISTOR KTC3875-GR 1 2216175R2
1
Q6401 or TRANSISTOR 2SC2712-GR ( 1) 2213145R2
1
Q6451 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q6452 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q6453 TRANSISTOR 2SA1163-BL(TE85L_F) 1 2216756R2
1
Q6454 TRANSISTOR 2SA1163-BL(TE85L_F) 1 2216756R2
1
Q6600 TRANSISTOR KRC105S 1 2217290R2
1
Q6600 or TRANSISTOR RN1405 ( 1) 2214500R2
1
Q6601 TRANSISTOR KRC105S 1 2217290R2
1
Q6601 or TRANSISTOR RN1405 ( 1) 2214500R2
[TRANS COIL]
1
L1000 CHOKE COIL LBC2518T2R2M 1 231364M022R2
1
L1001 CHOKE COIL LBC2518T2R2M 1 231364M022R2
1
L1002 CHOKE COIL LBC2518T2R2M 1 231364M022R2
1
L1003 CHOKE COIL LBC2518T470M 1 231364M470R2
1
L1004 CHOKE COIL LBC2518T470M 1 231364M470R2
1
L1005 EMI SUPPRESSION FILTER BK1608HS102-T 1 230955R2
1
L1006 EMI SUPPRESSION FILTER BK1608HS102-T 1 230955R2
[CAPACITOR]
1
C1001 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-101J1 1 342101014R1
1
C1002 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-101J1 1 342101014R1
1
C1003 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K1 1 332121045R1
1
C1004 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K1 1 332121045R1
1
C1005 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-080D1 1 342100802R1
1
C1006 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-080D1 1 342100802R1
C1007 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W25V-220M(UTSP) 1 397552217T
1
C1008 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
1
C1009 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
1
C1011 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-330J1 1 342103304R1
C1013 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W25V-220M(UTSP) 1 397552217T
1
C4003 UPZ TYPE PLASTIC FILM CAPACITOR 2AUPZTF221JE 1 376332214T
1
C4004 UPZ TYPE PLASTIC FILM CAPACITOR 2AUPZTF221JE 1 376332214T
1
C4009 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-221J1 1 342102214R1
1
C4010 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-221J1 1 342102214R1
1
C4013 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-221J1 1 342102214R1

Onkyo HT-RC630 Specifications

General

Output level	100 mV
Receiver type	Surround
Frequency range	5 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Dynamic power per channel (3 Ohm)	160 W
Dynamic power per channel (4 Ohm)	125 W
Dynamic power per channel (8 Ohm)	85 W
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	6
Audio (L/R) in	7
Composite video in	4
Digital audio coaxial in	2
Component video (YPbPr/YCbCr) in	1
Speakers connectivity type	-
Bluetooth	Yes
Ethernet LAN	No
Bluetooth version	2.1+EDR
Bluetooth profiles	A2DP, AVRCP
AM band range	522 - 1710 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Product color	Black
Audio decoders	Dolby TrueHD, DTS-HD Master Audio
Damping factor	60
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W
Package weight	10500 g

Weight and Dimensions

Depth	321 mm
Width	435 mm
Height	150 mm
Weight	8100 g
