Onkyo HT-RC630 User Manual

10/38 PAGE
1
R6200 CHIP TYPE CARBON RESISTOR RN72K1J-562JE 1 435035624R1
1
R6201 CHIP TYPE CARBON RESISTOR RN72K1J-562JE 1 435035624R1
1
R6202 CHIP TYPE CARBON RESISTOR RN72K1J-562JE 1 435035624R1
1
R6203 CHIP TYPE CARBON RESISTOR RN72K1J-104FE 1 435031042R1
1
R6204 CHIP TYPE CARBON RESISTOR RN72K1J-104FE 1 435031042R1
1
R6210 CHIP TYPE CARBON RESISTOR RN72K1J-472JE 1 435034724R1
1
R6211 CHIP TYPE CARBON RESISTOR RN72K1J-472JE 1 435034724R1
1
R6212 CHIP TYPE CARBON RESISTOR RN72K1J-472JE 1 435034724R1
1
R6213 CHIP TYPE CARBON RESISTOR RN72K1J-104FE 1 435031042R1
1
R6214 CHIP TYPE CARBON RESISTOR RN72K1J-104FE 1 435031042R1
1
R6220 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
1
R6221 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
1
R6222 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
1
R6223 CHIP TYPE CARBON RESISTOR RN72K1J-220FE 1 435032202R1
1
R6224 CHIP TYPE CARBON RESISTOR RN72K1J-220FE 1 435032202R1
1
R6230 CHIP TYPE CARBON RESISTOR RN72K1J-471JE 1 435034714R1
1
R6231 CHIP TYPE CARBON RESISTOR RN72K1J-471JE 1 435034714R1
1
R6232 CHIP TYPE CARBON RESISTOR RN72K1J-471JE 1 435034714R1
1
R6233 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
1
R6234 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
1
R6240 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
1
R6241 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
1
R6242 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
1
R6243 CHIP TYPE CARBON RESISTOR RN72K1J-472FE 1 435034722R1
1
R6244 CHIP TYPE CARBON RESISTOR RN72K1J-472FE 1 435034722R1
1
R6402 CHIP TYPE CARBON RESISTOR RN72K1J-102JE 1 435031024R1
1
R6403 CHIP TYPE CARBON RESISTOR RN72K1J-473JE 1 435034734R1
1
R6440 METAL RESISTOR RNU1WCJ-8.2 1 453630824T
1
R6441 METAL RESISTOR RNU1WCJ-8.2 1 453630824T
1
R6442 METAL RESISTOR RNU1WCJ-8.2 1 453630824T
1
R6443 METAL RESISTOR RNU1WCJ-8.2 1 453630824T
1
R6444 METAL RESISTOR RNU1WCJ-8.2 1 453630824T
1
R6451 CHIP TYPE CARBON RESISTOR RN72K1J-333JE 1 435033334R1
1
R6452 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 1 435031034R1
1
R6453 CHIP TYPE CARBON RESISTOR RN72K1J-223JE 1 435032234R1
1
R6454 CHIP TYPE CARBON RESISTOR RN72K1J-473JE 1 435034734R1
1
R6455 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 1 435031034R1
1
R6456 CHIP TYPE CARBON RESISTOR RN72K1J-223JE 1 435032234R1
1
R6457 CHIP TYPE CARBON RESISTOR RN72K1J-223JE 1 435032234R1
1
R6458 CHIP TYPE CARBON RESISTOR RN72K1J-562JE 1 435035624R1
1
R6459 CHIP TYPE CARBON RESISTOR RN72K1J-562JE 1 435035624R1
1
R6460 CHIP TYPE CARBON RESISTOR RN72K1J-473JE 1 435034734R1
1
R6690 METAL OXIDE FILM RESISTOR RS1/2WBJ-10 1 443521004T
[SW TRM]
1
F6401A FUSE HOLDER NSCT-1P2031 1 25052133T
!
1
F6401B FUSE HOLDER NSCT-1P2031 1 25052133T
!
1
F6402A FUSE HOLDER NSCT-1P2031 1 25052133T
!
1
F6402B FUSE HOLDER NSCT-1P2031 1 25052133T
!
P1000 ST JACK MSJ-035-22 1 25045887
P1001 PIN JACK NPJ-2PDOO626 1 25045847
1
P1002 TRM-423(SCREW) NEJITANSI ST3 1 25060495
P101B SOCKET NSCT-7P2100 1 25052203
P4002 PIN JACK NPJ-4PDWWRR624 1 25045845
P4003 PIN JACK NPJ-4PDWWRR624 1 25045845
P4004 PIN JACK NPJ-4PDWWRR624 1 25045845
P4009 PIN JACK NPJ-2PDWR558 1 25045776
P4011 PIN JACK NPJ-1PDP555 1 25045773
P501 WIRE HARNESS ASSEMBLY NSAS-3P2094 1 2009991283UL
1
P501A WIRE HOL NSCT-3P874 1 25051087
1
P501Aor WIRE HOL CHD-1.5-3 ( 1) 25053535
1
P5506B TERMINAL NTM-1P232(M1700) 1 25060301
1
P5507A TERMINAL NTM-1P232(M1700) 1 25060301

Onkyo HT-RC630 Specifications

General

Output level	100 mV
Receiver type	Surround
Frequency range	5 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Dynamic power per channel (3 Ohm)	160 W
Dynamic power per channel (4 Ohm)	125 W
Dynamic power per channel (8 Ohm)	85 W
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	6
Audio (L/R) in	7
Composite video in	4
Digital audio coaxial in	2
Component video (YPbPr/YCbCr) in	1
Speakers connectivity type	-
Bluetooth	Yes
Ethernet LAN	No
Bluetooth version	2.1+EDR
Bluetooth profiles	A2DP, AVRCP
AM band range	522 - 1710 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Product color	Black
Audio decoders	Dolby TrueHD, DTS-HD Master Audio
Damping factor	60
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W
Package weight	10500 g

Weight and Dimensions

Depth	321 mm
Width	435 mm
Height	150 mm
Weight	8100 g
