1
P5508 TRM-423(SCREW) NEJITANSI ST3 1 25060495
1
P5509A TERMINAL NTM-1P232(M1700) 1 25060301
P6000B PLUG NPLG-9P0964 1 25056014
P6001B PLUG NPLG-9P0964 1 25056014
P6002B PLUG NPLG-9P0964 1 25056014
P6004B PLUG NPLG-9P0964 1 25056014
P6013B PLUG NPLG-9P0964 1 25056014
1
P603A WIRE HOL NSCT-9P900 1 25051113
1
P603Aor WIRE HOL CHD-2.5-9 ( 1) 25053543
1
P603B WIRE HOL NSCT-9P900 1 25051113
1
P603Bor WIRE HOL CHD-2.5-9 ( 1) 25053543
P605B PLUG NPLG-5P119 1 25055135
P6080 PLUG NPLG-2P29 1 25055038
P6081 PLUG NPLG-2P29 1 25055038
P6082 PLUG NPLG-2P29 1 25055038
P6083 PLUG NPLG-2P29 1 25055038
P6084 PLUG NPLG-2P29 1 25055038
1
P6104 HOLDER HOLDER(CLAMP) 1 27190540-1
P6201 PLUG NPLG-5P152 1 25055168
1
P6400A CRIMP CORD ASSEMBLY CLIMP AS 1 2069925080UL
1
P6401A CRIMP CORD ASSEMBLY CRIMP AS 1 2069925142UL
1
P6402A CRIMP CORD ASSEMBLY CRIMP AS 1 2069925226UL
P6600 TERMINAL NTM-10PDML363 1 25060434
1
P660A WIRE HOL NSCT-7P898 1 25051111
1
P660Aor WIRE HOL CHD-2.5-7 ( 1) 25053542
1
P660B WIRE HOL NSCT-7P898 1 25051111
1
P660Bor WIRE HOL CHD-2.5-7 ( 1) 25053542
P703B PLUG NPLG-3P131 1 25055147
P8001B SOCKET NSCT-21P2412 1 25052515
P8003B SOCKET NSCT-9P2243 1 25052346
P801A SOCKET NSCT-7P2398 1 25052501
RL643 RELAY NRL-1P10A-DC12-196 1 25065707
RL643 or RELAY NRL-1P10A-DC12-197 ( 1) 25065708
RL643 or RELAY NRL-1P10A-DC12-198 ( 1) 25065709
RL644 RELAY NRL-1P10A-DC12-196 1 25065707
RL644 or RELAY NRL-1P10A-DC12-197 ( 1) 25065708
RL644 or RELAY NRL-1P10A-DC12-198 ( 1) 25065709
RL6600 RELAY NRL-2P5A-DC24-129 1 25065563A
RL6601 RELAY NRL-2P5A-DC24-129 1 25065563A
RL6602 RELAY NRL-2P5A-DC24-129 1 25065563A
U003 BACLA-1522-2A : NSP
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
1
D5000 ZENER DIODE DZ2J056M0L 1 224760560R2
1
D5000 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1
D5001 ZENER DIODE DZ2J056M0L 1 224760560R2
1
D5001 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1
D5002 ZENER DIODE DZ2J056M0L 1 224760560R2
1
D5002 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1
D5003 ZENER DIODE DZ2J056M0L 1 224760560R2
1
D5003 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1
D5004 ZENER DIODE DZ2J056M0L 1 224760560R2
1
D5004 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1
Q5000 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q5001 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q5002 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q5003 TRANSISTOR 2SC2713-BL 1 2213136R2

Onkyo HT-RC630 Specifications

General

Output level	100 mV
Receiver type	Surround
Frequency range	5 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Dynamic power per channel (3 Ohm)	160 W
Dynamic power per channel (4 Ohm)	125 W
Dynamic power per channel (8 Ohm)	85 W
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	6
Audio (L/R) in	7
Composite video in	4
Digital audio coaxial in	2
Component video (YPbPr/YCbCr) in	1
Speakers connectivity type	-
Bluetooth	Yes
Ethernet LAN	No
Bluetooth version	2.1+EDR
Bluetooth profiles	A2DP, AVRCP
AM band range	522 - 1710 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Product color	Black
Audio decoders	Dolby TrueHD, DTS-HD Master Audio
Damping factor	60
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W
Package weight	10500 g

Weight and Dimensions

Depth	321 mm
Width	435 mm
Height	150 mm
Weight	8100 g
