R5193 NON-FLAMMABLE CARBON FILM RESISTOR R25J-10 1 415471004T
R5194 NON-FLAMMABLE CARBON FILM RESISTOR R25J-10 1 415471004T
R5200 NON-FLAMMABLE CARBON FILM RESISTOR R25J-33K 1 415473334T
R5201 NON-FLAMMABLE CARBON FILM RESISTOR R25J-33K 1 415473334T
R5202 NON-FLAMMABLE CARBON FILM RESISTOR R25J-33K 1 415473334T
R5203 NON-FLAMMABLE CARBON FILM RESISTOR R25J-33K 1 415473334T
R5204 NON-FLAMMABLE CARBON FILM RESISTOR R25J-33K 1 415473334T
1
R5290 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 1 435031034R1
1
R5291 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 1 435031034R1
1
R5292 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 1 435031034R1
1
R5300 CHIP TYPE CARBON RESISTOR RN72K1J-151JE 1 435031514R1
1
R5301 CHIP TYPE CARBON RESISTOR RN72K1J-151JE 1 435031514R1
1
R5302 CHIP TYPE CARBON RESISTOR RN72K1J-151JE 1 435031514R1
1
R5303 CHIP TYPE CARBON RESISTOR RN72K1J-151JE 1 435031514R1
1
R5304 CHIP TYPE CARBON RESISTOR RN72K1J-151JE 1 435031514R1
1
R5310 CHIP TYPE CARBON RESISTOR RN72K1J-151JE 1 435031514R1
1
R5311 CHIP TYPE CARBON RESISTOR RN72K1J-151JE 1 435031514R1
1
R5312 CHIP TYPE CARBON RESISTOR RN72K1J-151JE 1 435031514R1
1
R5313 CHIP TYPE CARBON RESISTOR RN72K1J-151JE 1 435031514R1
1
R5314 CHIP TYPE CARBON RESISTOR RN72K1J-151JE 1 435031514R1
1
R5390 CHIP TYPE CARBON RESISTOR RN72K1J-821JE 1 435038214R1
1
R5391 CHIP TYPE CARBON RESISTOR RN72K1J-821JE 1 435038214R1
1
R5392 CHIP TYPE CARBON RESISTOR RN72K1J-821JE 1 435038214R1
1
R5393 CHIP TYPE CARBON RESISTOR RN72K1J-122FE 1 435031222R1
1
R5394 CHIP TYPE CARBON RESISTOR RN72K1J-222FE 1 435032222R1
1
R6013 CHIP TYPE CARBON RESISTOR RN72K1J-152FE 1 435031522R1
1
R6014 CHIP TYPE CARBON RESISTOR RN72K1J-152FE 1 435031522R1
R6020 NON-FLAMMABLE CARBON FILM RESISTOR R25J-2.2 1 415470224T
R6021 NON-FLAMMABLE CARBON FILM RESISTOR R25J-2.2 1 415470224T
R6022 NON-FLAMMABLE CARBON FILM RESISTOR R25J-2.2 1 415470224T
R6023 NON-FLAMMABLE CARBON FILM RESISTOR R25J-2.2 1 415470224T
R6024 NON-FLAMMABLE CARBON FILM RESISTOR R25J-2.2 1 415470224T
1
R6033 CHIP TYPE CARBON RESISTOR RN72K1J-152FE 1 435031522R1
1
R6034 CHIP TYPE CARBON RESISTOR RN72K1J-152FE 1 435031522R1
1
R6040 TRIMMER RESISTOR N06HR1KBB 1 5211401T
1
R6041 TRIMMER RESISTOR N06HR1KBB 1 5211401T
1
R6042 TRIMMER RESISTOR N06HR1KBB 1 5211401T
1
R6050 CHIP TYPE CARBON RESISTOR RN72K1J-152JE 1 435031524R1
1
R6051 CHIP TYPE CARBON RESISTOR RN72K1J-152JE 1 435031524R1
1
R6052 CHIP TYPE CARBON RESISTOR RN72K1J-152JE 1 435031524R1
1
R6053 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
1
R6054 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
R6070 NON-FLAMMABLE CARBON FILM RESISTOR R25J-100 1 415471014T
R6071 NON-FLAMMABLE CARBON FILM RESISTOR R25J-100 1 415471014T
R6072 NON-FLAMMABLE CARBON FILM RESISTOR R25J-100 1 415471014T
R6073 NON-FLAMMABLE CARBON FILM RESISTOR R25J-120 1 415471214T
R6074 NON-FLAMMABLE CARBON FILM RESISTOR R25J-120 1 415471214T
[SW TRM]
1
P5507B TERMINAL NTM-1P233(M1969) 1 25060302
1
P5509B TERMINAL NTM-1P233(M1969) 1 25060302
P6000A SOCKET NSCT-9P2189 1 25052292
P6001A SOCKET NSCT-9P2189 1 25052292
P6002A SOCKET NSCT-9P2189 1 25052292
P6003A SOCKET NSCT-9P2189 1 25052292
P6004A SOCKET NSCT-9P2189 1 25052292
U004 BADIS-1658-1A : NSP
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS

Onkyo HT-RC630 Specifications

General

Output level	100 mV
Receiver type	Surround
Frequency range	5 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Dynamic power per channel (3 Ohm)	160 W
Dynamic power per channel (4 Ohm)	125 W
Dynamic power per channel (8 Ohm)	85 W
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	6
Audio (L/R) in	7
Composite video in	4
Digital audio coaxial in	2
Component video (YPbPr/YCbCr) in	1
Speakers connectivity type	-
Bluetooth	Yes
Ethernet LAN	No
Bluetooth version	2.1+EDR
Bluetooth profiles	A2DP, AVRCP
AM band range	522 - 1710 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Product color	Black
Audio decoders	Dolby TrueHD, DTS-HD Master Audio
Damping factor	60
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W
Package weight	10500 g

Weight and Dimensions

Depth	321 mm
Width	435 mm
Height	150 mm
Weight	8100 g
