[SEMI CONDUCTOR]
D201 DIODE G10XB80-02-60A-T16 1 22380378F
D201 or DIODE D5SBA60 ( 1) 22380070F
1
D202 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D202 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D203 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D203 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D204 ZENER DIODE DZ2J062M0L 1 224760620R2
1
D204 or ZENER DIODE UDZS6.2B ( 1) 224550620R2
1
D2101 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D2101 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D2102 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D2102 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D7002 ZENER DIODE DZ2J082M0L 1 224760820R2
1
D7002 or ZENER DIODE UDZS8.2B ( 1) 224550820R2
1
D7033 ZENER DIODE DZ2J039M0L 1 224760390R2
1
D7033 or ZENER DIODE UDZS3.9B ( 1) 224550390R2
D7152 LED SLI-343Y8C-3F 1 225491
1
D7301 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D7301 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D7302 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D7302 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D7303 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D7304 CHIP TYPE DIODE DA2J10100 1 223303R2
D7654 LED SCB3318E-D2 1 225487
1
D7654A HOLDER (LED)LH-5-5 1 27191312
D7655 LED SCB3318E-D2 1 225487
1
D7655A HOLDER (LED)LH-5-5 1 27191312
1
D911 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D911 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D912 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D912 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D921 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D921 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D922 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D922 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D923 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D923 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D924 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D924 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D925 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D925 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D930 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D930 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D931 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D931 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D934 ZENER DIODE UDZS5.1B 1 224550510R2
1
D934 or ZENER DIODE DZ2J051M0L ( 1) 224760510R2
1
D941 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D941 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D942 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D942 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D960 DIODE RL1N4003 1 22380260T
1
D961 DIODE RL1N4003 1 22380260T
1
D962 ZENER DIODE DZ2J360M0L 1 224763600R2
1
D962 or ZENER DIODE UDZS36B ( 1) 224553600R2
1
Q2001 HYBRID IC NJW1328 1 22242691R3
Q7002 FLUORESCENT TUBE 16-BT-168GNK 1 212279
1
Q7002A HOLDER (FL) 1 27191222C
1
Q7003 HYBRID IC ML9208A-13GA 1 22242772R3
1
Q7004 TRANSISTOR KTC3875-GR 1 2216175R2
1
Q7004 or TRANSISTOR 2SC2712-GR ( 1) 2213145R2

Onkyo HT-RC630 Specifications

General

Output level	100 mV
Receiver type	Surround
Frequency range	5 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Dynamic power per channel (3 Ohm)	160 W
Dynamic power per channel (4 Ohm)	125 W
Dynamic power per channel (8 Ohm)	85 W
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	6
Audio (L/R) in	7
Composite video in	4
Digital audio coaxial in	2
Component video (YPbPr/YCbCr) in	1
Speakers connectivity type	-
Bluetooth	Yes
Ethernet LAN	No
Bluetooth version	2.1+EDR
Bluetooth profiles	A2DP, AVRCP
AM band range	522 - 1710 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Product color	Black
Audio decoders	Dolby TrueHD, DTS-HD Master Audio
Damping factor	60
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W
Package weight	10500 g

Weight and Dimensions

Depth	321 mm
Width	435 mm
Height	150 mm
Weight	8100 g
