Onkyo HT-RC630 User Manual

17/38 PAGE
1
Q7006 TRANSISTOR KTC3875-GR 1 2216175R2
1
Q7006 or TRANSISTOR 2SC2712-GR ( 1) 2213145R2
1
Q7010 TRANSISTOR KTC3875-GR 1 2216175R2
1
Q7010 or TRANSISTOR 2SC2712-GR ( 1) 2213145R2
1
Q7011 TRANSISTOR KRA107S 1 2216350R2
1
Q7011 or TRANSISTOR RN1407 ( 1) 2216260R2
1
Q7012 TRANSISTOR KRC107S 1 2216340R2
1
Q7012 or TRANSISTOR RN1407 ( 1) 2216260R2
1
Q7033 TRANSISTOR KTC3875-GR 1 2216175R2
1
Q7033 or TRANSISTOR 2SC2712-GR ( 1) 2213145R2
Q7041 REMOTE SENSOR IRM-3638M3S28 1 24130026
1
Q7711 HYBRID IC BU2090F-E2 1 22242686R2
1
Q911 TRANSISTOR KRC105S 1 2217290R2
1
Q911 or TRANSISTOR RN1405 ( 1) 2214500R2
1
Q911 or TRANSISTOR DTC123JKA ( 1) 2216690R2
1
Q960 TRANSISTOR KTC4373-Y 1 2218120R2
1
Q960 or TRANSISTOR 2SC2881-Y ( 1) 2217564AR2
1
Q960 or TRANSISTOR INC5001AP1-T111 ( 1) 2218100R2
[TRANS COIL]
1
L7031 CHOKE COIL LBC2518T2R2M 1 231364M022R2
1
L7032 CHOKE COIL LBC2518T2R2M 1 231364M022R2
1
L7201 CHOKE COIL LBC2518T2R2M 1 231364M022R2
1
L7202 CHOKE COIL LBC2518T2R2M 1 231364M022R2
1
L7203 CHOKE COIL LBC2518T2R2M 1 231364M022R2
T902 POWER TRANSFORMER NPT-1520JQ 1 2301812A
!
[CAPACITOR]
1
C2000 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
1
C2001 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
C2003 JAMICON TYPE ELECTROLYTIC CAPACITOR CE04W50V-2.2M 1 398580227T
C2003 or VR TYPE ELECTROLYTIC CAPACITOR CE04W50V-2.2M(VR) ( 1) 394680227T
1
C2004 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
1
C2008 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
1
C2009 CHIP TYPE CERAMIC CAPACITOR CK725F1A-105Z1 1 332181050R1
C201 JAMICON TYPE ELECTROLYTIC CAPACITOR CE04W25V-4700M 1 398554727S
N
C201 or VR TYPE ELECTROLYTIC CAPACITOR CE04W25V-4700M(VR) ( 1) 394654727S
1
C2010 CHIP TYPE CERAMIC CAPACITOR CK725F1A-105Z1 1 332181050R1
1
C2012 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
1
C2013 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
1
C2014 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
1
C2015 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
C202 JAMICON TYPE ELECTROLYTIC CAPACITOR CE04W50V-4.7M 1 398580477T
C202 or VR TYPE ELECTROLYTIC CAPACITOR CE04W50V-4.7M(VR) ( 1) 394680477T
1
C203 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-334J 1 374723344T
C207 JAMICON TYPE ELECTROLYTIC CAPACITOR CE04W6.3V-470M 1 398524717T
C207 or VR TYPE ELECTROLYTIC CAPACITOR CE04W6.3V-470M(VR) ( 1) 394624717T
1
C208 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
C2101 JAMICON TYPE ELECTROLYTIC CAPACITOR CE04W50V-2.2M 1 398580227T
C2101 or VR TYPE ELECTROLYTIC CAPACITOR CE04W50V-2.2M(VR) ( 1) 394680227T
C2102 JAMICON TYPE ELECTROLYTIC CAPACITOR CE04W50V-2.2M 1 398580227T
C2102 or VR TYPE ELECTROLYTIC CAPACITOR CE04W50V-2.2M(VR) ( 1) 394680227T
C2103 JAMICON TYPE ELECTROLYTIC CAPACITOR CE04W50V-2.2M 1 398580227T
C2103 or VR TYPE ELECTROLYTIC CAPACITOR CE04W50V-2.2M(VR) ( 1) 394680227T
C2106 JAMICON TYPE ELECTROLYTIC CAPACITOR CE04W6.3V-470M 1 398524717T
C2106 or VR TYPE ELECTROLYTIC CAPACITOR CE04W6.3V-470M(VR) ( 1) 394624717T
C2107 JAMICON TYPE ELECTROLYTIC CAPACITOR CE04W6.3V-470M 1 398524717T
C2107 or VR TYPE ELECTROLYTIC CAPACITOR CE04W6.3V-470M(VR) ( 1) 394624717T
C2108 JAMICON TYPE ELECTROLYTIC CAPACITOR CE04W6.3V-470M 1 398524717T
C2108 or VR TYPE ELECTROLYTIC CAPACITOR CE04W6.3V-470M(VR) ( 1) 394624717T
C2109 JAMICON TYPE ELECTROLYTIC CAPACITOR CE04W6.3V-470M 1 398524717T
C2109 or VR TYPE ELECTROLYTIC CAPACITOR CE04W6.3V-470M(VR) ( 1) 394624717T
C2110 JAMICON TYPE ELECTROLYTIC CAPACITOR CE04W50V-2.2M 1 398580227T
C2110 or VR TYPE ELECTROLYTIC CAPACITOR CE04W50V-2.2M(VR) ( 1) 394680227T
