Onkyo TX-DS494

TX-DS494/HT-R490
C3388,C3488 354744709 47uF,16V, Elect.
C3471,C3481 354781009 10uF,50V, Elect.
C3571,C3581 354781009 10uF,50V, Elect.
C3588,C3688 354744709 47uF,16V, Elect.
C3594,C3595 354741009 10uF,16V, Elect.
C3671,C3681 354781009 10uF,50V, Elect.
C3687 374724734 0.047uF+/-5%,50V, Plastic
Jacks
P301,P302 25045300 or NPJ-6PDBL159 or
25045571 NPJ-6PDRW386
P7202 25045645 NPJ-2PDO450 <494>
Sockets
P303,P305 25051527 NSCT-16P1314
P304 25051526 NSCT-4P1313
P306 25051230 NSCT-5P1020
P391 2009990579UL NSAS-16P0788
P601 2009990652UL NSAS-10P0907
C816,C817 374721524 1500pF+/-5%, 50V, Plastic
C827,C829 354744709 47uF,16V, Elect.
C830,C831 354784709 47uF,50V, Elect.
C832 374721544 0.15upF+/-5%, 50V, Plastic
C833,C846,C847 374721524 1500pF+/-5%, 50V, Plastic
C834,C836 374726834 0.068uF+/-5%, 50V, Plastic
C835,C837 374726814 680pF+/-5%, 50V, Plastic
C840,C842 354744709 47uF,16V, Elect.
C844,C845 354784709 47uF,50V, Elect.
C848-C851 374726814 680pF+/-5%, 50V, Plastic
C854,C857,C868 354744709 47uF,16V, Elect.
C858,C859 354784709 47uF,50V, Elect.
C860,C861 374721524 1500pF+/-5%, 50V, Plastic
C862-C865 374726814 680pF+/-5%, 50V, Plastic
C871 ,C880,C882 354744709 47uF,16V, Elect.
C886 374721034 0.01uF+/-5%, 50V, Plastic
C894,C896 354744709 47uF,16V, Elect.
Jacks
P201 25045567 NPJ-1PDBL382
P202 25045315 NPJ-2PDYE172
P203 25045299 NPJ-3PDYE158
Sockets
P702B 25052029 or NSCT-20P1816 or
25050960 or NSCT-20P747 or
25051286 or NSCT-20P1075 or
25051827 or NSCT-20P1614 or
25052216 NSCT-20P2113
P704 25051237 NSCT-12P1027
P705 25051241 NSCT-20P1031
P706 25051230 NSCT-5P1020
P707 25051526 NSCT-4P1313
Plug
P701A 25055136 NPLG-6P120
U14
INPUT TERMINAL PC BOARD
(NAAF-7050-1A/1B/1C/1D/1F/1G/1H)
CIRCUIT NO.
PART NO. DESCRIPTION
ICs
Q301 22240864 TC9273N-004
Q302,Q3181,Q3183 22241383R2 NJM4565M-D
Q3171 22241371 TC9482N
Q3281,Q3381,Q3581 22241383R2 NJM4565M-D
Transistors
Q3182,Q3184 2213632 or RN1241-B or
2213631 RN1241-A
Q3185 2214350 or RN2202 or
2213510 or DTA114ES or
2215770 KRA102M
Q3282,Q3284 2213632 or RN1241-B or
2213631 RN1241-A
Q3384,Q3484 2213632 or RN1241-B or
2213631 RN1241-A
Q3584,Q3684,Q3685 2213631 or RN1241-A or
2213632 RN1241-B
Diodes
D401,D402,D3182 223234R2 or 1SS352 or
223269R2 1SS355
Capacitors
C315,C316 354744709 47uF,16V, Elect.
C3171,C3271 354781009 10uF,50V, Elect.
C3172,C3173 354744709 47uF,16V, Elect.
C3181,C3281 354782209 22uF,50V, Elect.
C3183,C3188 354744709 47uF,16V, Elect.
C3189,C3289 374721534 0.015uF+/-5%,50V, Plastic
C3190,C3196 354741009 10uF,16V, Elect.
C3194,C3195 354744709 47uF,16V, Elect.
C321,C322 354784709 47uF,50V, Elect.
C323,C324 354744709 47uF,16V, Elect.
C3283,C3288 354744709 47uF,16V, Elect.
C3290,C3394,C3395 354741009 10uF,16V, Elect.
C3371,C3381 354781009 10uF,50V, Elect.
Coils
L201 231237M022R2 NCH-1471
L701-L703 231237M022R2 NCH-1471
L704,L705 230921R2 BLM21B222SPT,Choke coil
L720-L722 231237M022R2 NCH-1471
L802,L803 231237M022R2 NCH-1471
X701 3010327 or AT-4912.288MHz or
3010320 or AT-49 12.288MHz or
3010335 AT-49H12.288MHz,Crystal
X702 3010324R2 CSTCV12.2MTJ0C4,Cera lock
Capacitors
C201-C203 354780229 2.2uF,50V, Elect.
C205,C206 354724719 470uF,6.3V, Elect.
C210,C701,C708 354721019 100uF,6.3V, Elect.
C3691 374721044 0.1uF+/-5%, 50V, Plastic
C740,C741 354721019 100uF,6.3V, Elect.
C788,C791 354724719 470uF,6.3V, Elect.
C807,C810 354721019 100uF,6.3V, Elect.
C811,C825 354741009 10uF,16V, Elect.
Diodes
D201,D202 223234R2 or 1SS352 or
223269R2 1SS355
D801-D808 223234R2 or 1SS352 or
223269R2 1SS355
Q202,Q3690 2215410R2 RN1441
Q3691 2214540R2 RN2403
NOTE:
<DD> : 120V model only
: Asian model only for 120V
<GT> : Asian model only for 230V
<PP> : European model only
<WT> : World wide model only
<WR> : Chinese model only
<494>: TX-DS494 only
<490>: HT-R490 only
<DT>
NOTE:THE COMPONENTS IDENTIFIED BY MARK   ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE ONLY WITH  P ART NUMBER SPECIFIED.
CIRCUIT NO.
PART NO. DESCRIPTION
<PA> : Australian model only
Oscillator
PRINTED CIRCUIT BOARD PARTS LIST-5
