Onkyo TX-DS494

TX-DS494/HT-R490
REF. NO. PART NO. DESCRIPTION
1 27111200 Front bracket <B>
27111201 Front bracket <S>
27111202 Front bracket <G>
2 27141787 Retainer, HP
3 838130088
3TTB+8B, Self tapping screw
4 82143010 3P+10FN(BC), Self tapping screw
6 27100368B Chassis
7 27190266
KGLS-12RF, Holder
8 27190428A KGLS-10RF, Holder
9 27190813 KGPS-10RF, Holder
12 830440089 4TTC+8C(BC), Self tapping screw
14 27300750 Bushing, cord #2271 <DD,PP,WR,WT, PA,GT>
15 27160435 Heat sink L
17 801433
3SMS8W.SW+14B(BC), Special screw
18 27141681 Retainer, PWB
20 27141735 Retainer, Rear
21 27141734 Retainer, Front
24 27160436A Heat sink S
25 82143010
3P+10FN(BC) Pan head screw
26 29362772 Label, cover
27 27141729 Retainer, S
28 838430068
3TTB+6B(BC), Self tapping screw
29 29110083 Tape, Cross-16U
32 27215357 Decorative frame <B>
27215359 Decorative frame <S>
27215358 Decorative frame <G>
33 28325497A Knob, power <B>
28325547A Knob, power <S>
28325499A Knob, power <G>
34 28191911 Clear plate <B>
28191912 Clear plate <S,G>
36 28184663-1 Top cover <B>
28184666 Top cover <S>
28184682 Top cover <G>
37 28141408 Cushion
38 838430088
3TTB+8B(BC), Self tapping screw <B>
838930088 3TTB+8B(UN), Self tapping screw <S, G>
39 27175319A Leg
40 28141332 Cushion, leg
41 831430088 3TTW+8B(BC), Self tapping screw
42 28325641 Knob, Volume <B>
28325642 Knob, Volume <S>
28325643 Knob, Volume <G>
43 28325405 Knob, tone <B>
28325474 Knob, tone <S>
28325407 Knob, tone <G>
44 27191130 Holder, outlet <WR>
45 27122810 Rear panel <DD>
27122811 Rear panel <PP>
27122813 Rear panel <WT>
27122814 Rear panel <WR>
27122815 Rear panel <PA>
27122812 Rear panel <GT>
27122824A Rear panel <490>
46 87643010
W3*10F(BC), Flat washer
47 838930088 3TTB+8B(UN), Self tapping screw
48 27212285 Front panel <B> <DD, WT, WR, PA>
27212286 Front panel <B> <PP>
27212287 Front panel <S> <PP>
27212288 Front panel <G> <PA, WR, WT, GT>
27212292 Front panel <490>
49 28198778 Facet
50 28135244 Badge <B>
28135245 Badge <S,G>
D910 22380038 or RBV602 or
22380274
RS603M, Diode
E811 223024 Isolated sheet, AC238
E891 880048
P-3055B-8L, Plastic rivet
F911 252166 6.3A-UL/T-237, Fuse <DD,WT,WR,490>
F922 252077 or 4A-SE-EAK or
252243 4A-SE-TL250V, Fuse <PP,WT,WR,GT,PA>
F923 252075 2.5A-SE-EAK, Fuse <PP>
P101 2047151512 NCFC7-151512, Flexible flat cable
P7001 2047252012 NCFC7-252012, Flexible flat cable
P702 2047202022 NCFC7-202022, Flexible flat cable
REF. NO. PART NO. DESCRIPTION
[NOTE]
<DD> : 120V model only
<DT> : Asian model only for 120V
<GT> : Asian model only for 230V
<PP> : European model only
<WT> : World wide model only
<WR> : Chinese model only
<494> : TX-DS494 only
<490> : HT-R490 only
<B> : Black model only
<S> : Silver model only
<G> : Golden model only
NOTE: THE COMPONENTS IDENTIFIED BY MARK
ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH
PART NUMBER SPECIFIED.
EXPLODED VIEW PARTS LIST-1
