Onkyo TX-NR3007

216/219 PAGE
PCB-U008
P6017A SOCKET NSCT-3P2183 1 25052286
PCB-U008
P6018A SOCKET NSCT-3P2183 1 25052286
PCB-U008
P6030B SOCKET IMSA-9115S-05L 1 25052985 N
PCB-U008
P6031B SOCKET IMSA-9115S-05L 1 25052985 N
PCB-U008
P6032B SOCKET IMSA-9115S-05L 1 25052985 N
PCB-U008
P6033B SOCKET IMSA-9115S-05L 1 25052985 N
PCB-U008
P6034B SOCKET IMSA-9115S-05L 1 25052985 N
PCB-U008
P6035B SOCKET IMSA-9115S-05L 1 25052985 N
PCB-U008
P6036B SOCKET IMSA-9115S-05L 1 25052985 N
PCB-U008
P6037B SOCKET IMSA-9115S-05L 1 25052985 N
PCB-U008
P6038B SOCKET IMSA-9115S-05L 1 25052985 N
PCB-U010
U0101 FRONT HDMI PC BOARD (BAHDM-0291-1B)
PCB-U010
PCB-U010
CIRCUIT.
N
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
PCB-U010
[SEMI CONDUCTOR]
PCB-U010
D3300 C-DIODE KDS4148U 1 223283R2
PCB-U010
D3300 or C-DIODE 1SS352 ( 1) 223234R2
PCB-U010
D3301 C-DIODE KDS4148U 1 223283R2
PCB-U010
D3301 or C-DIODE 1SS352 ( 1) 223234R2
PCB-U010
D8861 C-DIODE KDS4148U 1 223283R2
PCB-U010
D8861 or C-DIODE 1SS352 ( 1) 223234R2
PCB-U010
D8862 C-DIODE KDS4148U 1 223283R2
PCB-U010
D8862 or C-DIODE 1SS352 ( 1) 223234R2
PCB-U010
Q3300 IC TPD2E001DRLR 1 22242589R2
PCB-U010
Q8861 IC TMDS141RHARG4 1 22242586R2
PCB-U010
[TRANS COIL]
PCB-U010
L8861 CORE BLM18PG181SN1D 1 2350005R1
PCB-U010
[CAPACITOR]
PCB-U010
C3302 C-FILM C ECHU16V-104J 1 373041044R2
PCB-U010
C3303 C-FILM C ECHU16V-104J 1 373041044R2
PCB-U010
C3304 C-CERA C CK725F1A-105Z1 1 332181050R1
PCB-U010
C8861 C-FILM C ECHU16V-104J 1 373041044R2
