Onkyo TX-NR7100

183
Appendix
General Specications
Amplier Section North American models European models Australian and Asian models
Rated Output Power
With 8 ohm loads, both channels
driven, from 20-20,000 Hz; rated
100 watts per channel minimum
RMS power, with no more than
0.08% total harmonic distortion from
250 milliwatts to rated output. (FTC)
9 ch × 170 W at 6 ohms, 1 kHz, 1 ch driven of 1% THD (IEC)
Maximum Effective Output Power
220 W at 6 ohms, 1 kHz, 1 ch driven
of 10% THD
185 W at 6 ohms, 1 kHz, 1 ch driven
of 10% THD (JEITA)
9 ch × 185 W at 6 ohms, 1 kHz, 1 ch
driven of 10% THD (JEITA)
THD+N (Total Harmonic Distortion + Noise) 0.08% (20 Hz - 20,000 Hz, Rated output power)
Input Sensitivity and Impedance 200 mV/47 kΩ (LINE(RCA)), 3.5 mV/47 kΩ (PHONO MM)
Rated RCA Output Level and Impedance
PRE OUT (SUBWOOFER) : 1 V/470 Ω
LINE OUT (ZONE 2/ZONE B) :
200 mV/2.2 kΩ
PRE OUT (FRONT) : 1 V/470 Ω
LINE OUT (ZONE 2/ZONE B) : 200 mV/470 Ω
Phono Maximum Input Signal Voltage 70 mV (MM 1 kHz 0.5%)
Frequency Response 10 Hz - 100 kHz/+1 dB, –3 dB (Direct/Pure Audio)
Tone Control Characteristics ±10 dB, 20 Hz (BASS), ±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 106 dB (IHF-A, LINE IN, SP OUT), 80 dB (IHF-A, PHONO IN, SP OUT)
Speaker Impedance 4 Ω - 16 Ω
Headphone Rated Output 80 mW + 80 mW (32 Ω, 1 kHz, 10% THD)
Supported impedance of Headphones 8 Ω - 600 Ω
Headphones Frequency Response 10 Hz - 100 kHz
