Onkyo TX-NR7100

5.1. 2ch
7.1.2c h
5.1.4ch
5.1c h
7.1ch
23
Speaker Layout
5.1.2 Channel System
A Speaker System that is a 5.1 Channel System with one set of height speakers added.
5.1.2 ch (Front High or Rear High) ( →p29) 5.1.2 ch (Top Front or Top Middle or Top Rear)
( →p29)
5.1.2 ch (Dolby Enabled Speakers (Front or
Surround)) ( →p29)
Zone 2Zone 2
Main Room
5.1.2 ch + ZONE 2 ( →p29) 5.1.2 ch (Bi-Amping (Front)) ( →p29)
