Speaker Connections
Connecting a Power Amplier (For European, Australian and Asian models)
You can connect a power amplier to the unit and use the unit as a pre-amplier
in order to produce a large volume that cannot be output with the unit only.
Connect the front speakers to the power amplier. For details, refer to the power
amplier's instruction manual.
• Use the PRE OUT FRONT jacks for connection as show on the left.
Setup
• Set "2. Speaker" - "Conguration" - "Speaker Channels" according to the
number of channels of the connected speakers.
a Analog audio cable
a
Power amplier
