Onkyo TX-NR7100

190
Appendix
Audio Inputs North American models European models Australian and Asian models
Analog 8 (Including 1×PHONO, 1×AUX(Front))
Digital 2 (C OA XI A L×1, O P T I CA L×1)
Audio Outputs North American models European models Australian and Asian models
Analog
LINE OUT (ZONE 2)(*) × 1
PRE OUT (SUBWOOFER) × 2
*Can be changed to LINE OUT
(ZONE B).
LINE OUT (ZONE 2)(*) × 1
PRE OUT (FRONT) × 1
PRE OUT (SUBWOOFER) × 2
*Can be changed to LINE OUT (ZONE B).
Speaker Outputs
9 (FRONT L/R, CENTER, SURROUND L/R, HEIGHT 1 L/R or ZONE 2 L/R, HEIGHT 2 L/R or SURROUND
BACK L/R or ZONE 3 L/R )
• North American models are banana plug ready.
Phones 1 (ø 6.3 mm, 1/4")
Others North American models European models Australian and Asian models
Setup Mic 1 (Front)
RS-232 1
12V TRIGGER OUT 1 (100mA)
IR 1 (IN)
Specications and features are subject to change without notice.
