Onkyo TX-SR302

3/26 PAGE
EXP
U09
VIDEO & OPT TERMINAL PCB ASSY
NAVD-7867-3B 1 1A978567-3B
EXP
U10
REGULATOR PCB ASSY
NAETC-7868-3B 1 1A978568-3B
EXP
U11
TERMINAL PCB ASSY
NAETC-7869-3B 1 1A978569-3B
EXP
U12
SPEAKER TERMINAL PCB ASSY
NAETC-7870-3B 1 1A978570-3B
EXP
U17
POWER AMPLIFIER PCB ASSY
NAAF-7875-2F 1 1A978575-2F
EXP
U18
TERMINAL PCB ASSY
NAPS-7876-2F 1 1A978576-2F
EXP
U19
POWER SUPPLY PCB ASSY
NAPS-7877-2F 1 1A978577-2F
EXP
U20
TERMINAL PCB ASSY
NAPS-7878-2F 1 1A978578-2F
EXP
U23
HOLDER PCB ASSY
NAETC-7881-2F 1 1A978581-2F
EXP
U25
TERMINAL PCB ASSY
NAETC-7884-2F 1 1A978584-2F
EXP
U26
THERMAL SENSOR PCB ASSY
NAETC-8256-2F 1 1A978556-2F
EXP
U27 TUNER UNIT TFCE1U114B 1 240134A
EXP
U27 or TUNER UNIT FAE385-A02F ( 1) 240146
EXP
<Note 1>
EXP
There are two kinds of products of this unit.
EXP
Use the parts corresponding to each products about the following parts.
EXP
REF. NO. : A401 REAR PANEL
EXP
<MDD> = MADE IN MALAYSIA, <UDD> = MADE IN JAPAN
EXP
<Note 2>
EXP
When replacement the following the transistor, made from the same HFE rank as the original type.
EXP
Q6050 - Q6055, Q6060 - Q6065
TX-SR302
PC BOARD PARTS LIST
U01 PRE-AMPLIFIER PC BOARD(NADG-7401-3F)
REF. NO. NAME DESCRIPTION Q'TY PART NO. REMARKS
PCB-1
Q301 IC BD3811K1 1 22241761R3
PCB-1
Q302 IC NJM4565M-D 1 22241383R2
PCB-1
Q302 or IC MPC4570G2-T1(MST) ( 1) 22240489R1NE
PCB-1
Q302 or IC NJM4565M ( 1) 22240581R2
PCB-1
Q305 IC NJM4565M-D 1 22241383R2
PCB-1
Q305 or IC MPC4570G2-T1(MST) ( 1) 22240489R1NE
PCB-1
Q305 or IC NJM4565M ( 1) 22240581R2
PCB-1
Q306 TR RN2402 1 2214530R2
PCB-1
Q306 or TR KRA102S ( 1) 2216220R2
PCB-1
Q307 TR RN1441 1 2215410R2
PCB-1
Q308 TR RN1441 1 2215410R2
PCB-1
Q312 TR RN1441 1 2215410R2
PCB-1
Q313 TR RN1441 1 2215410R2
PCB-1
Q321 IC(REGULATOR) 78L07(SMT) 1 222780073R2
PCB-1
Q322 IC(REGULATOR) 79L07(SMT) 1 222790073R2
PCB-1
Q701 IC CS493264 1 22241762R2
PCB-1
Q707 IC TC7WU04FU 1 22240935R2
PCB-1
Q801 IC AK4586 1 22241620R3
PCB-1
Q802 IC NJM4565M-D 1 22241383R2
PCB-1
Q802 or IC MPC4570G2-T1(MST) ( 1) 22240489R1NE
PCB-1
Q802 or IC NJM4565M ( 1) 22240581R2
PCB-1
Q803 IC NJM4565M-D 1 22241383R2
PCB-1
Q803 or IC MPC4570G2-T1(MST) ( 1) 22240489R1NE
PCB-1
Q803 or IC NJM4565M ( 1) 22240581R2
PCB-1
Q804 IC NJM4565M-D 1 22241383R2
PCB-1
Q804 or IC MPC4570G2-T1(MST) ( 1) 22240489R1NE
PCB-1
Q804 or IC NJM4565M ( 1) 22240581R2
PCB-1
Q6402 IC(REGURATOR) 7812HF(TA7812S) 1 222780124TOS
PCB-1
Q6402 or IC(REGULATOR) 78M12HF ( 1) 222780125
PCB-1
Q6402A SCREW 3P+10FN(BC) 1 82143010
PCB-1
Q6402B HEAT SINK RAD-183 1 27160526
PCB-1
Q6402C TAPE TAPE(CLOTH-16U) 1 29110083
PCB-1
Q6403 IC(REGURATOR) 79012HF(TA79012S) 1 222790124TOS
PCB-1
Q6403 or IC(REGULATOR) 79M12HF ( 1) 222790125
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
