Onkyo TX-SR302

11/26 PAGE
PCB-1
R7073 C-CARBON R RN72K1J-221JE 1 435032214R1
PCB-1
R7074 C-CARBON R RN72K1J-221JE 1 435032214R1
PCB-1
R7075 C-CARBON R RN72K1J-221JE 1 435032214R1
PCB-1
R7076 C-CARBON R RN72K1J-102JE 1 435031024R1
PCB-1
R7077 C-CARBON R RN72K1J-102JE 1 435031024R1
PCB-1
R7078 C-CARBON R RN72K1J-333JE 1 435033334R1
PCB-1
R7079 C-CARBON R RN72K1J-333JE 1 435033334R1
PCB-1
R7080 C-CARBON R RN72K1J-103JE 1 435031034R1
PCB-1
R7081 C-CARBON R RN72K1J-221JE 1 435032214R1
PCB-1
R7082 C-CARBON R RN72K1J-221JE 1 435032214R1
PCB-1
R7083 C-CARBON R RN72K1J-221JE 1 435032214R1
PCB-1
R7084 C-CARBON R RN72K1J-221JE 1 435032214R1
PCB-1
R7085 C-CARBON R RN72K1J-221JE 1 435032214R1
PCB-1
R7120 C-CARBON R RN72K1J-102JE 1 435031024R1
PCB-1
R7134 C-CARBON R RN72K1J-102JE 1 435031024R1
PCB-1
R7138 C-CARBON R RN72K1J-223JE 1 435032234R1
PCB-1
R7178 C-CARBON R RN72K1J-563JE 1 435035634R1
PCB-1
R7179 C-CARBON R RN72K1J-472JE 1 435034724R1
PCB-1
R7180 C-CARBON R RN72K1J-333JE 1 435033334R1
PCB-1
R7839 C-CARBON R RN72K1J-223JE 1 435032234R1
PCB-1
R9506 METAL O R RS1/2WBJ-22 1 443522204
PCB-1
R9507 C-CARBON R RN72K1J-153JE 1 435031534R1
PCB-1
R9508 C-CARBON R RN72K1J-153JE 1 435031534R1
PCB-1
R9509 C-CARBON R RN72K1J-104JE 1 435031044R1
PCB-1
P101 SOCKET NSCT-15P2108 1 25052211
PCB-1
P101 or SOCKET NSCT-15P1811 ( 1) 25052024
PCB-1
P301 PIN JACK NPJ-6PDRW386 1 25045571
PCB-1
P301 or PIN JACK NPJ-6PDBL159 ( 1) 25045300
PCB-1
P301 or PIN JACK NPJ-6PDWWWRRR561 ( 1) 25045779
PCB-1
P302 PIN JACK NPJ-2PDBL185 1 25045333
PCB-1
P302 or PIN JACK NPJ-2PDWR558 ( 1) 25045776
PCB-1
P304 PIN JACK NPJ-6PDRW386 1 25045571
PCB-1
P304 or PIN JACK NPJ-6PDBL159 ( 1) 25045300
PCB-1
P304 or PIN JACK NPJ-6PDWWWRRR561 ( 1) 25045779
PCB-1
P305 PIN JACK NPJ-6PWRLGGP493 1 25045697
PCB-1
P305 or PIN JACK NPJ-6PDWLGREP562 ( 1) 25045780
PCB-1
P306 SOCKET AS NSAS-20P1004 1 2009990717UL
PCB-1
P351 PIN JACK NPJ-1PDP510 1 25045720
PCB-1
P351 or PIN JACK NPJ-1PDP555 ( 1) 25045773
PCB-1
P410B PLUG NPLG-10P662 1 25055706
PCB-1
P411B PLUG NPLG-10P662 1 25055706
PCB-1
P412B PLUG NPLG-8P660 1 25055704
PCB-1
P801 PLUG NPLG-14P666 1 25055710
PCB-1
P6403 RETAINER KANAGU 1 27141059
PCB-1
P7502B SOCKET NSCT-10P2473 1 25052576R2
PCB-1
E300 RETAINER KANAGU 1 27141059
U02 DISPLAY PC BOARD(NADIS-7403-3B)
U03 SWITCH PC BOARD(NASW-7404-3B)
U04 HEADPHONE JACK PC BOARD(NAETC-7405-3B)
<Notes>
Indicate the parts on the PC board ass'y of U02-U04 collectively. Not dividing into each PC board ass'y.
REF. NO. NAME DESCRIPTION Q'TY PART NO. REMARKS
PCB-2
U7501 REMO SENS SPS-444-1-VP 1 241352
PCB-2
Q7501 FL TUBE 16BT123GK 1 212250
PCB-2
Q7501A HOLDER (FL) 1 27190989B
PCB-2
Q7502 IC MPD780232GC-030-8BT 1 22241571R3
PCB-2
Q7503 TR KTC3875-GR 1 2216175R2
PCB-2
Q7503 or TR 2SC2712-GR ( 1) 2213145R2
PCB-2
Q7504 TR KRA103S 1 2216230R2
PCB-2
Q7504 or TR RN2403 ( 1) 2214540R2
PCB-2
Q7506 TR KRC102S 1 2216190R2
PCB-2
Q7506 or TR RN1402 ( 1) 2214470R2
