Onkyo TX-SR302 - Page 54

14/26 PAGE
PCB-2
S7632 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB-2
S7633 PUSH SW NPS-111-S681 1 25035718
PCB-2
S7633 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB-2
S7634 PUSH SW NPS-111-S681 1 25035718
PCB-2
S7634 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB-2
S7635 PUSH SW NPS-111-S681 1 25035718
PCB-2
S7635 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB-2
S7636 PUSH SW NPS-111-S681 1 25035718
PCB-2
S7636 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB-2
S7637 PUSH SW NPS-111-S681 1 25035718
PCB-2
S7637 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB-2
S7641 PUSH SW NPS-111-S681 1 25035718
PCB-2
S7641 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB-2
S7642 PUSH SW NPS-111-S681 1 25035718
PCB-2
S7642 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB-2
S7642 or PUSH SW NPS-111-S681 ( 1) 25035718
PCB-2
S7643 PUSH SW NPS-111-S681 1 25035718
PCB-2
S7643 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB-2
S7644 PUSH SW NPS-111-S681 1 25035718
PCB-2
S7644 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB-2
S7645 PUSH SW NPS-111-S681 1 25035718
PCB-2
S7645 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB-2
S7646 PUSH SW NPS-111-S681 1 25035718
PCB-2
S7646 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB-2
S7647 PUSH SW NPS-111-S681 1 25035718
PCB-2
S7647 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB-2
E7501 RETAINER KANAGU 1 27141059
PCB-2
JL7501A WIRE HOL NSCT-3P894 1 25051107
PCB-2
JL7501B WIRE HOL NSCT-3P894 1 25051107
PCB-2
JL7502A WIRE HOL NSCT-5P896 1 25051109
PCB-2
JL7502B WIRE HOL NSCT-5P896 1 25051109
U08 DRIVER AMPLIFIER PC BOARD(NAAF-7866-3B)
U09 VIDEO & OPT TERMINAL PC BOARD(NAVD-7867-3B)
U10 REGULATOR PC BOARD(NAETC-7868-3B)
U11 TERMINAL PC BOARD(NAETC-7869-3B)
U12 SPEAKER TERMINAL PC BOARD(NAETC-7870-3B)
<Notes>
Indicate the parts on the PC board ass'y of U08-U12 collectively. Not dividing into each PC board ass'y.
REF. NO. NAME DESCRIPTION Q'TY PART NO. REMARKS
PCB-3
U281 PHT CP TORX179L 1 24120101
PCB-3
Q201 TR RN1241-A 1 2213631
PCB-3
Q201 or TR RN1241-B ( 1) 2213632
PCB-3
Q202 TR RN1241-A 1 2213631
PCB-3
Q202 or TR RN1241-B ( 1) 2213632
PCB-3
Q203 IC LA7956 1 22241759
PCB-3
Q204 TR KTA1267-GR 1 2215995
PCB-3
Q204 or TR 2SA933S-R ( 1) 2213354
PCB-3
Q205 TR KRA102M 1 2215770
PCB-3
Q205 or TR DTA114ES ( 1) 2213510
PCB-3
Q206 TR KRA102M 1 2215770
PCB-3
Q206 or TR DTA114ES ( 1) 2213510
PCB-3
Q281 IC 74HCU04F 1 222740046R2
PCB-3
Q5000 TR KTC3200-BL 1 2215896
PCB-3
Q5000 or TR 2SC1775A-E ( 1) 2210755
PCB-3
Q5000 or TR 2SC1775A-F ( 1) 2210756
PCB-3
Q5000 or TR 2SC1845-E ( 1) 2211733
PCB-3
Q5001 TR KTC3200-BL 1 2215896
PCB-3
Q5001 or TR 2SC1775A-E ( 1) 2210755
PCB-3
Q5001 or TR 2SC1775A-F ( 1) 2210756
PCB-3
Q5001 or TR 2SC1845-E ( 1) 2211733
PCB-3
Q5002 TR KTC3200-BL 1 2215896
PCB-3
Q5002 or TR 2SC1775A-E ( 1) 2210755
