En-7
'
Subwoofer with
built-in power
amplifier
&
Surround R
%
Surround L
$
Center
1/2˝-5/8˝
(12-15 mm)
3/8˝-1/2˝
(10-12 mm)
#
Front R
"
Front L
3 Connecting Speakers
"
$
%
&
'
#
" #
Front speakers
$
Center speaker
% &
Surround speakers
'
Subwoofer
Important:
Connect speakers with 6 Ω to 16 Ω impedance. Using
a speaker with less impedance than the supported
value may result in failure.
Characteristics of speaker types
"# output front stereo sound and $ outputs center sound
such as dialogs and vocals. %& create back sound field.
' reproduces bass sounds and creates rich sound field.
