Features
Amp
• 7-channel amplifier
• 75 watts per channel min. RMS at 8 Ω, 2 channels
driven from 20 Hz to 20 kHz with no more than 0.08%
total harmonic distortion
• WRAT (Wide Range Amplifier Technology)
• Optimum gain volume circuitry
Processing
• Dolby
1
Digital EX and Dolby Pro Logic IIx
• DTS, DTS-ES Matrix/Discrete, DTS Neo:6, and DTS
96/24 processing
2
• Cinema Filter function
• Linear PCM 192 kHz/24-bit D/A converters on all
channels
• Pure Audio listening mode (not North American
model)
• Powerful and highly accurate 32-bit DSP Processing
Audio/Video
• Adjustable crossover (60, 80, 100, 120, 150 Hz)
• HDTV-capable component video (3 inputs, 1 output)
• 3 S-Video inputs, 2 outputs
• 4 assignable digital inputs (3 optical, 1 coaxial)
• Subwoofer pre out
• Color-coded multichannel input for use with Super
Audio CD and DVD-Audio
• A/B speaker drive
• Color-coded speaker terminal posts
FM/AM Tuner
• 30 FM/AM presets
• FM/AM auto tuning
• RDS (Radio Data System) (Europe only)
Remote Controller
• Preprogrammed for use with other AV components
Table of Contents
Important Safety Instructions.................2
Precautions ..............................................3
Supplied Accessories .............................4
Features....................................................5
Front & Rear Panels ................................6
Before Using the AV receiver................... 9
Remote Controller .................................10
Connecting Your Speakers...................15
Connecting Antenna .............................18
Connecting the AV receiver ................... 20
Turning On .............................................30
First Time Setup ....................................31
Playing Your AV Components..............34
Using the Tuner .....................................36
Common Functions...............................40
Using the Listening Modes...................42
Adjusting the Listening Modes ............46
Recording...............................................48
Advanced Setup ....................................49
Controlling Other Components............52
1. Manufactured under license from Dolby Laboratories.
“Dolby”, “Pro Logic” and the double-D symbol are regis-
tered trademarks of Dolby Laboratories.
2. “DTS,” “DTS 96/24,” “DTS-ES,” and “Neo:6” are trade-
marks of Digital Theater Systems, Inc.
Introduction
Connection
Turning On & First Time Setup
Basic Operation
Enjoying the Listening Modes
Advanced Operation
Troubleshooting .................................... 55
Specification.......................................... 58
