Onkyo TX-SR573 - Connecting Satellite, Cable, and Set-Top Boxes; External Source Video;Audio Connections

26
Connecting Your Components—Continued
• With connection , you can listen to and record audio from the video source and listen via speaker set B.
• To enjoy Dolby and DTS listening modes, use connection or . (For recording, use and , or and .)
Connecting a Satellite, Cable, Set-top Box, or Other Video Source
Connection AV receiver Signal flow Video source Picture quality
COMPONENT VIDEO VIDEO 2 IN
⇐
Component video output Best
VIDEO 2 IN S
⇐
S-Video output Better
VIDEO 2 IN V
⇐
Composite video output Standard
Y
P
B
PR
Y
P
B
PR
COMPONENT VIDEO
VIDEO 2 IN
COMPONENT VIDEO
OUT
S VIDEO OUT
VIDEO OUT
VIDEO 2
IN
IN
V
S
VIDEO 2
Step 1: Video Connection
Choose a connection that matches the video source ( , , or
), and then make the connection.
A B C
A
B
C
Satellite, cable,
set-top box, etc.
Your TV must be con-
nected to the AV
receiver via the same
type of connection.
A
B
C
Connection AV receiver Signal flow Video source
VIDEO 2 IN L/R
⇐
Analog audio L/R output
DIGITAL IN COAXIAL
⇐
Digital coaxial output
DIGITAL IN OPTICAL 2
⇐
Digital optical output
L
R
VIDEO 2
IN
L
R
AUDIO
OUT
OPTICAL
2
OPTICAL
OUT
DIGITAL IN
COAXIAL
COAXIAL
OUT
Step 2: Audio Connection
Choose a connection that matches the video source ( , , or ), and then make the connection.
a b c
a
b
c
Satellite, cable,
set-top box, etc.
Connect one
or the other
a
b c
a
b a c
a
b
c
