Connecting Your Components—Continued
■ CD Player or Turntable with Built-in Phono Preamp
• With connection , you can listen to and record from your CD player or turntable and listen via speaker set B.
• To connect the CD player digitally, use connection or . (For recording, use and , or and .)
■ Turntable with no Phono Preamp Built-in
A phono preamp is necessary to connect a turntable that
doesn’t have a phono preamp built-in.
■ Turntable with an MC (Moving Coil) Cartridge
An MC head amp and phono preamp are necessary to
connect a turntable with an MC (Moving Coil) cartridge.
Connecting a CD Player or Turntable
