Onkyo TX-SR603E

1/42 PAGE
<Notes>
(B) : Black model
(S) : Silver model
(G) : Golden model
<DC> : TX-SR603 Canadian model
<DD> : TX-SR603 American model
<GK> : TX-SR603 Korean model
<GQ> : TX-SR603 Hong kong model
<GR> : TX-SR603 Chinese model
<PA> : TX-SR603 Australian model
<WT> : TX-SR603 World wide model
<PP> : TX-SR603E European model
<8360>: TX-SR8360 Chinese model
EXPLODED VIEW PARTS LIS
T
REF. NO. NAME DESCRIPTION Q'TY PART NO REMARKS
EXP
A001 F BRACKET TX-SR603(B)MDD 1 27111395A (B), <DD>
EXP
A001 F BRACKET TX-SR603(B)MDD 1 27111395A (B), <DC>
EXP
A001 F BRACKET TX-SR603(B)MDD 1 27111395A (B), <PA>
EXP
A001 F BRACKET TX-SR603(B)MDD 1 27111395A (B), <WT>
EXP
A001 F BRACKET TX-SR603E(B)MPP 1 27111396A <PP>(, B)
EXP
A001 F BRACKET TX-SR603(S)MDC 1 27111397A <DC>, (S)
EXP
A001 F BRACKET TX-SR603(S)MDC 1 27111397A <PA>, (S)
EXP
A001 F BRACKET TX-SR603E(S)MPP 1 27111398A <PP>, (S)
EXP
A001 F BRACKET TX-SR603(G)MGR 1 27111400A <GK>, (G)
EXP
A001 F BRACKET TX-SR603(G)MGR 1 27111400A <GR>, (G)
EXP
A001 F BRACKET TX-SR603(G)MGR 1 27111400A <GQ>, (G)
EXP
A001 F BRACKET TX-SR603(G)MGR 1 27111400A <WT>, (G)
EXP
A001 F BRACKET TX-SR603(G)MGR 1 27111400A <8360>
EXP
A002 SCREW 3TTB+8B(CU)SR 39 801618
EXP
A005 KNOB (SEL-L) 1 28326308 (B)
EXP
A005 KNOB (SEL-L) 1 28326310 (G)
EXP
A005 KNOB (SEL-L) 1 28326311 (S)
EXP
A006 KNOB (SEL-R) 1 28326312 (B)
EXP
A006 KNOB (SEL-R) 1 28326314 (G)
EXP
A006 KNOB (SEL-R) 1 28326315 (S)
EXP
A007 FACET (ST) 1 28198998A
EXP
A013 WIRE TIE BSK-1 8 260208
EXP
A014 CLIP CS-1U 1 27255004
EXP
A015 CHASSIS --- 1 27100461A
EXP
A017 TAPE TAPE(CLOTH-16U) (1) 29110083
EXP
A018 HOLDER KGLS-22S 1 27190369
EXP
A020 HOLDER KGLS-14RT 3 27190524
EXP
A021 HOLDER HOLDER 2 27190991
EXP
A022 BRACKET (B) 1 27130987
EXP
A030 SCREW 4TTC+8C(BC) 4 830440089
EXP
A031 SPACER --- 1 27270439
EXP
A033 LABEL (PT) 1 29363379-1
EXP
A035 WIRE TIE BSK-1 4 260208
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
TX-SR603X/603E/8360
