5/42 PAGE
EXP
U08
HOLDER PC board ass'y
NAETC-8520-1P 1 1B068520-1P <8360>
EXP
U08
HOLDER PC board ass'y
NAETC-8520-1Q 1 1B068520-1Q <PP>
EXP
U09
AMPLIFIER PC board ass'y
NAAF-8523-1K 1 1B068523-1K <DD, DC>
EXP
U09
AMPLIFIER PC board ass'y
NAAF-8523-1L 1 1B068523-1L <PP>
EXP
U09
AMPLIFIER PC board ass'y
NAAF-8523-1L 1 1B068523-1L <8360>
EXP
U09
AMPLIFIER PC board ass'y
NAAF-8523-1L 1 1B068523-1L <PA, WT>
EXP
U09
AMPLIFIER PC board ass'y
NAAF-8523-1L 1 1B068523-1L <GK, GR, GQ>
EXP
U10
SEC. TERMINAL-2 PC board ass'y
NAPS-8524-1K 1 1B068524-1K <DD, DC>
EXP
U10
SEC. TERMINAL-2 PC board ass'y
NAPS-8524-1L 1 1B068524-1L <PP>
EXP
U10
SEC. TERMINAL-2 PC board ass'y
NAPS-8524-1L 1 1B068524-1L <8360>
EXP
U10
SEC. TERMINAL-2 PC board ass'y
NAPS-8524-1L 1 1B068524-1L <PA, WT>
EXP
U10
SEC. TERMINAL-2 PC board ass'y
NAPS-8524-1L 1 1B068524-1L <GK, GR, GQ>
EXP
U11
SBR AMPLIFIER PC board ass'y
NAETC-8525-1K 1 1B068525-1K <DD, DC>
EXP
U11
SBR AMPLIFIER PC board ass'y
NAETC-8525-1L 1 1B068525-1L <PP>
EXP
U11
SBR AMPLIFIER PC board ass'y
NAETC-8525-1L 1 1B068525-1L <8360>
EXP
U11
SBR AMPLIFIER PC board ass'y
NAETC-8525-1L 1 1B068525-1L <PA, WT>
EXP
U11
SBR AMPLIFIER PC board ass'y
NAETC-8525-1L 1 1B068525-1L <GK, GR, GQ>
EXP
U12
THERMAL SENSOR PC board ass'y
NAETC-8526-1K 1 1B068526-1K <DD, DC>
EXP
U12
THERMAL SENSOR PC board ass'y
NAETC-8526-1L 1 1B068526-1L <PP>
EXP
U12
THERMAL SENSOR PC board ass'y
NAETC-8526-1L 1 1B068526-1L <8360>
EXP
U12
THERMAL SENSOR PC board ass'y
NAETC-8526-1L 1 1B068526-1L <PA, WT>
EXP
U12
THERMAL SENSOR PC board ass'y
NAETC-8526-1L 1 1B068526-1L <GK, GR, GQ>
EXP
U13
HOLDER PC board ass'y
NAETC-8527-1K 1
1B068527-1K
<DD, DC>
EXP
U13
HOLDER PC board ass'y
NAETC-8527-1L 1
1B068527-1L
<PP>
EXP
U13
HOLDER PC board ass'y
NAETC-8527-1L 1
1B068527-1L
<8360>
EXP
U13
HOLDER PC board ass'y
NAETC-8527-1L 1
1B068527-1L
<PA, WT>
EXP
U13
HOLDER PC board ass'y
NAETC-8527-1L 1
1B068527-1L
<GK, GR, GQ>
EXP
U15
POWER SUPPLY-1 PC board ass'y
NAPS-8533-1M 1 1B068533-1M <DD, DC>
EXP
U15
POWER SUPPLY-1 PC board ass'y
NAPS-8533-1N 1 1B068533-1N <PA>
EXP
U15
POWER SUPPLY-1 PC board ass'y
NAPS-8533-1P 1 1B068533-1P <WT>
EXP
U15
POWER SUPPLY-1 PC board ass'y
NAPS-8533-1Q 1 1B068533-1Q <GR>, <8360>
EXP
U15
POWER SUPPLY-1 PC board ass'y
NAPS-8533-1R 1 1B068533-1R <GK>
EXP
U15
POWER SUPPLY-1 PC board ass'y
NAPS-8533-1T 1 1B068533-1T <GQ> <PP>
EXP
U17
POWER SUPPLY-2 PC board ass'y
NAPS-8535-1M 1 1B068535-1M <DD, DC>
EXP
U17
POWER SUPPLY-2 PC board ass'y
NAPS-8535-1N 1 1B068535-1N <PA>
EXP
U17
POWER SUPPLY-2 PC board ass'y
NAPS-8535-1P 1 1B068535-1P <WT>
EXP
U17
POWER SUPPLY-2 PC board ass'y
NAPS-8535-1Q 1 1B068535-1Q <GR>, <8360>
EXP
U17
POWER SUPPLY-2 PC board ass'y
NAPS-8535-1R 1 1B068535-1R <GK>
EXP
U17
POWER SUPPLY-2 PC board ass'y
NAPS-8535-1T 1 1B068535-1T <GQ> <PP>
EXP
U18
SEC. TERMINAL-1 PC board ass'y
NAPS-8536-1M 1 1B068536-1M <DD, DC>
EXP
U18
SEC. TERMINAL-1 PC board ass'y
NAPS-8536-1N 1 1B068536-1N <PA>
EXP
U18
SEC. TERMINAL-1 PC board ass'y
NAPS-8536-1P 1 1B068536-1P <WT>
EXP
U18
SEC. TERMINAL-1 PC board ass'y
NAPS-8536-1Q 1 1B068536-1Q <GR>, <8360>
EXP
U18
SEC. TERMINAL-1 PC board ass'y
NAPS-8536-1R 1 1B068536-1R <GK>
EXP
U18
SEC. TERMINAL-1 PC board ass'y
NAPS-8536-1T 1 1B068536-1T <GQ>, <PP>
EXP
U19
SPEAKER TERMINAL PC board ass'y
NAETC-8537-1M 1 1B068537-1M <DD, DC>
EXP
U19
SPEAKER TERMINAL PC board ass'y
NAETC-8537-1N 1 1B068537-1N <PA>
EXP
U19
SPEAKER TERMINAL PC board ass'y
NAETC-8537-1P 1 1B068537-1P <WT>
EXP
U19
SPEAKER TERMINAL PC board ass'y
NAETC-8537-1Q 1 1B068537-1Q <GR>, <8360>
EXP
U19
SPEAKER TERMINAL PC board ass'y
NAETC-8537-1R 1 1B068537-1R <GK>
EXP
U19
SPEAKER TERMINAL PC board ass'y
NAETC-8537-1T 1 1B068537-1T <GQ>, <PP>
EXP
U20
CENTER SPEAKER TERMINAL PC board ass'
NAETC-8538-1M 1 1B068538-1M <DD, DC>
EXP
U20
CENTER SPEAKER TERMINAL PC board ass'
NAETC-8538-1N 1 1B068538-1N <PA>
EXP
U20
CENTER SPEAKER TERMINAL PC board ass'
NAETC-8538-1P 1 1B068538-1P <WT>
EXP
U20
CENTER SPEAKER TERMINAL PC board ass'
NAETC-8538-1Q 1 1B068538-1Q <GR>, <8360>
EXP
U20
CENTER SPEAKER TERMINAL PC board ass'
NAETC-8538-1R 1 1B068538-1R <GK>
EXP
U20
CENTER SPEAKER TERMINAL PC board ass'
NAETC-8538-1T 1 1B068538-1T <GQ>, <PP>
EXP
U22
DRIVER AMPLIFIER PC board ass'y
NAAF-8540-1M 1 1B068540-1M <DD, DC>
EXP
U22
DRIVER AMPLIFIER PC board ass'y
NAAF-8540-1N 1 1B068540-1N <PA>
EXP
U22
DRIVER AMPLIFIER PC board ass'y
NAAF-8540-1P 1 1B068540-1P <WT>
EXP
U22
DRIVER AMPLIFIER PC board ass'y
NAAF-8540-1Q 1 1B068540-1Q <GR>, <8360>
EXP
U22
DRIVER AMPLIFIER PC board ass'y
NAAF-8540-1R 1 1B068540-1R <GK>
EXP
U22
DRIVER AMPLIFIER PC board ass'y
NAAF-8540-1T 1 1B068540-1T <GQ>, <PP>
EXP
U24 TUNER UNIT TFCE1U114B 1 240134A <DD, DC>
EXP
U24 TUNER UNIT TFCE1E512A 1 240135 <GK, GR, GQ>
EXP
U24 TUNER UNIT TFCE1E512A 1 240135 <PP, PA>
EXP
U24 TUNER UNIT TFCE1E512A 1 240135 <WT>
EXP
U24 TUNER UNIT TFCE1E512A 1 240135 <8360>
PC BOARD PARTS LIST
U01 VIDEO PC BOARD (NAVD-8476-1A/B)
CIRCUIT N
NAME DESCRIPTION Q'TY PART NO REMARKS
TX-SR603X/603E/8360
