10
INSTALLATION AND CONNECTION OF SQUEEGEE COMPONENT
1. Stop and place the machine on the level ground,
select the mode switch on the control panel to o.
Brushes and squeegee will automatically lift to the up
position, and take out the key.
2. Lower the lifting rod of the squeegee to the lower
position.
3. Install the squeegee to the squeegee installation
bracket as shown in the gure. Ensure to fully place the
fastening knob into the jack and then tighten the knob.
4. Connect the vacuum suction pipe to the squeegee
component.
5. Examine the squeegee adhesive tape and reasonably
adjust.
To Next Page
