Large MDUs (more than 12 units)
For larger MDUs there may be a
requirement to install multiple bre
boxes/splitters.
405mm
These boxes/splitters will be connected with
Duct 54 and bre cable commonly housed
within the riser space.
330mm
120mm
Array of ports for internal bre cable
located at bottom of bre DP/splitter
Multi Dwelling Units (MDUs)
