Furniture
Cable brackets and steps (where
required) are supplied in a bagged kit
and easily slot into purpose designed
pockets in the chamber. The brackets
and steps drop into preformed slots.
Available Size Range
Product Code Clear opening
Depth Per
Section
JMF104 915X445mm 150mm
JMF106 1310X610mm 150mm
Duct entries
Duct entries can be cut as and where required
using a hole saw mounted on a cordless drill.
The chambers incorporate guides which identify
drilling points to ensure correct duct spacing.
A maximum of 4 duct entries can be made into
a single wall of the Quadbox™.
Quadbox points of note
As with brick built chambers, care should be taken to make sure:
• The box is set at the correct depth and the base/ plinth is installed correctly.
• The side wall is not damaged/misshapen due to over compaction.
• The frame is level with the surface and a core drill is used for cutting duct entries.
• The developer is required to purchase the required wall bearers
Modular jointing chambers – Quadbox
TM
