11
Continues…
PRIMA OP PRIMA MAXI
PRIMA / P. MAXI PRIMA OP CLASSICA
(4) Gently insert the quick plug-in connector into the receiving connector
located on the solenoid lock at the indicated position.
PAY ATTENTION TO THE DIRECTION OF INSERTION.
4
32.5
23
255
32.5
(22/27/32)
8
8
23
23
16
14
72
198
28
355
42.5
42.5
8
8
23
23
14
26
85
