opti-solar SP5000 Initial-P - User Manual

33 pages

Save Page as PDF

Questions and Answers

J
jenkinsjohnAug 8, 2025
Why does my opti-solar Inverter work in battery mode when mains exist?
- C
  Christine WilsonAug 8, 2025
  If your opti-solar Inverter continues to operate in battery mode even when mains power is available, it could be due to a tripped input protector. In this case, verify that the AC breaker hasn't tripped and that the AC wiring is securely connected. Another cause could be insufficient AC power quality, especially when using shore power or a generator. To resolve this, check if the AC wires are adequately sized and not excessively long. If using a generator, ensure it is functioning correctly and that the input voltage range setting is correct for your UPS appliance.
C
Courtney RodriguezAug 18, 2025
What to do if my opti-solar Inverter has no response after power on?
- I
  inielsenAug 18, 2025
  If your opti-solar Inverter isn't responding after you power it on, the battery voltage might be too low. In this case, try to recharge the battery. Another possible cause is a tripped internal fuse. If this is the case, contact a repair center to replace the fuse.
Z
Zachary CollierAug 28, 2025
Why does my opti-solar Inverter shut down during startup?
- M
  Matthew LeeAug 28, 2025
  If your opti-solar Inverter shuts down automatically during the startup process, it's likely that the battery voltage is too low (less than 1.91V/Cell). To address this, first, try to recharge the battery. If the issue persists, consider replacing the battery.

Summary

Safety Instructions

Product Overview

Installation

Battery Connection

Steps and recommendations for connecting the battery, including cable size and torque values.

AC Input;Output Connection

Procedures for connecting AC input and output, including breaker recommendations and wire polarity.

PV Connection

Guidelines for connecting PV modules, including cable size and torque values.

Operation

Power ON;OFF

Simple instructions on how to turn the unit on and off using the switch.

Operation and Display Panel

Overview of the front panel components: LCD display, indicators, and function keys.

LCD Setting

Detailed guide on how to navigate and change various setting programs using the function keys.

Fault Reference Code

Lists fault codes, their corresponding events, and the icon displayed on the unit.

Warning Indicator

Specifications

Table 1 Line Mode Specifications

Table 2 Inverter Mode Specifications

Table 3 Charge Mode Specifications

Table 4 General Specifications

Trouble Shooting

opti-solar SP5000 Initial-P Specifications

General

MPPT Voltage Range	120-450 V
Nominal AC Power	5000 W
Nominal AC Voltage	230 V
Efficiency	97.5%
Protection Degree	IP65
Output Power	5000 W
Output Voltage	230V
Frequency	50/60 Hz
Operating Temperature Range	-25°C to +60°C
Waveform	Pure Sine Wave
