29
Frequency regulation ± 0.25 Hz (battery or free running mode)
* 60V at 40% load, 70V at 70%, 80V at 100%.
ENVIRONMENTAL
Ambient temperature: +0 °C to +40 °C
Recommended temperature: +15 °C to +25 °C
Storage temperature: -15 °C to +50 °C
Cooling: Forced air-cooling
Humidity: 0-95%, non-condensing
Audible noise: < 40 db normal and battery mode
10.4 Power Range 1000-3000 VA (220/230/240V 19” Rack-mount
model)
GENERAL
Rated power 1000 VA, 1500VA, 2000 VA, 3000 VA at p.f 0.7
Technology On-line, double conversion topology with automatic bypass
INPUT
Phase Single phase with ground
Bypass Voltage: 184-265 VAC (user selectable)
Input Voltage range: 120/140/160 VAC-276 VAC
Frequency: 50/60 Hz. Auto selection
Frequency window from mains 45-65 Hz
Synchronization window ± 3Hz.
Input current 1000 VA 4A, 1500 VA 6A, 2000 VA 7.7A, 3000 VA 12A
Input Power factor: 0.97
OUTPUT
Output Voltage: 208/220/230/240 VAC, selectable from LCD panel
Voltage regulation: ± 2%
Voltage distortion: < 5% THD at full non-linear load, < 3% THD at full linear load
Frequency regulation ± 0.25 Hz (battery or free running mode)
* 120V at 40% load, 140V at 70%, 160V at 100%.
Dynamic response: ± 9 % max from 100% to 20 % or from 20% to 100 % linear load
Overload capacity: 100-125% 1 min, 125-150% 10 sec
Efficiency: greater than 86%
ENVIRONMENTAL
Ambient temperature: +0 °C to +40 °C
Recommended temperature: +15 °C to +25 °C
Storage temperature: -15 °C to +50 °C
Cooling: Forced air-cooling
Humidity: 0-95%, non-condensing
Audible noise: < 40 db normal and battery mode
30
STANDARDS
Safety: EN50091-1-1
Emissions: EN50091-2 class B
Immunity: EN50091-2
100/110/120V Model
OUTPUT POWER 1000VA/700W 1500VA/1050W 2000VA/1400W 3000VA/2100W
Connection Input Attached power cord
Connection Output 6 x 5-15R (US) 6 x 5-15R (US) 12 x 5-15R (US) 12 x 5-15R (US)
Battery type
Lead-acid
7.2Ah/12V
Lead-acid
9Ah/12V
Lead-acid
7.2Ah/12V
Lead-acid
34W/12V
Number of batteries 3 3 6 6
Backup time/full load 6 min 6 min 6 min 5 min
Recharge time <4 hours to 90% <4 hours to 90% <4 hours to 90% <4 hours to 90%
Dimensions W x L x H mm 152 x 420 x 238 152 x 420 x 238 225 x 425 x 360 225 x 425 x 360
Weight kg 16.2 17 31.1 33
19” Rack-mount Model (2U)
OUTPUT
POWER
1000VA/700W 1500VA/1050W 2000VA/1400W 3000VA/2100W
Connection Input Attached power cord
Connection Output 6 x 5-15R (US) 6 x 5-15R (US) 4 x 5-15R (US) 4 x 5-15R (US)
Battery type
Lead-acid
7.2Ah/12V
Lead-acid
9Ah/12V
Lead-acid
7.2Ah/12V
Lead-acid
34W/12V
Number of
batteries
3 3 6 6
Backup time/full
load
6 min 6 min 6 min 5 min
Recharge time <4 hours to 90% <4 hours to 90% <4 hours to 90% <4 hours to 90%
Dimensions
W x L x H mm
428 x 425 x 84 428 x 425 x 84 428 x 635 x 84 428 x 635 x 84
Weight kg 17.1 18.1 31.6 32.5
19” Rack-mount Model (1U)
OUTPUT POWER 1000VA/ 700W
Connection Input Attached power cord
Connection Output
3 x 5-15R (US)
Battery type Lead-acid 7 Ah/ 6V
Number of batteries 4
Backup time/ full load 4 min
Recharge time <4 hours to 90%
Dimensions W x L x H mm 428 x 525 x 44
Weight kg 15.5
