24 DS-I 1-3k UPS User Manual
Annex B. EPO / External Battery Pack
EPO
EPO (emergency power off) is function to shutdown UPS completely at emergency condition.
This function can be activated through a remote contact provided by the user. It requires
opening NO and +24V at normal operation. EPO is activated when shorting NO and +24V.
Description of Input Port for Remote EPO
Position
Name
Purpose
P1
＋
24V
+24V, internal power supply
P2
EPO_NO
EPO is activated when shorting with +24V
EXTERNAL BATTERY PACK
Notice: 1. Please re-start the UPS after finish the parallel connection.
2. please finish the battery charging (8~16 hrs) before using.
SPEC of Battery pack
Model
BP-1000
BP-2000
BP-3000
DC
36V
72V
2x0Vac 96V,
1x0Vac 72V
Battery type
12V7Ah 3pcs 2set
12V7Ah 6pcs 1set
12V7Ah 8pcs 2set
12V7Ah 6pcs 1set
12V9Ah 3pcs 2set
12V9Ah 6pcs 1set
12V9Ah 8pcs 2set
12V9Ah 6pcs 1set
Dimension
(W*D*H)
144×353×222mm
1x0Vac : DC72V 14x353x222mm
2x0Vac : DC96V 190×502×335mm
Weight (kg)
16kg
20kg
DC96V 47kg, DC72V 20kg
