Installation
Version 1.0 dated 2015-03-31Page 8 Original operating instructions
DPA22GB
2.4 Power supply speed sensor
Power is supplied via the rear jack plug . Connect the sensor for speed measurement from the
scope of delivery with the electronic display.
2.5 Signal selection for input signal
 Up: Sine 11uApp
 Down TTL differential signal
Speed sensor connection
Jumper for reader signal selection
